SKF 32307 B Taper Roller 35 mm ID Tapered Roller Bearing, 80 mm OD
- RS Stock No.:
- 461-699
- Mfr. Part No.:
- 32307 B
- Brand:
- SKF
Subtotal (1 unit)*
£57.80
(exc. VAT)
£69.36
(inc. VAT)
FREE delivery for orders over £60.00
Stocked by manufacturer
- Ready to ship from 24 August 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £57.80 |
*price indicative
- RS Stock No.:
- 461-699
- Mfr. Part No.:
- 32307 B
- Brand:
- SKF
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | SKF | |
| Product Type | Tapered Roller Bearing | |
| Inside Diameter | 35mm | |
| Bore Type | Cylindrical | |
| Cage Material | Sheet Metal | |
| Standards/Approvals | UNSPSC, RoHS, eClass | |
| Series | 32307 B | |
| Limiting Speed | 8500rpm | |
| Bearing Dynamic Load Rating | 115kN | |
| Outside Diameter | 80mm | |
| Number of Rows | 1 | |
| Cup Width | 25mm | |
| Static Load Rating | 114kN | |
| Cone Width | 31mm | |
| Race Type | Cylindrical | |
| Bearing Type | Taper Roller | |
| Select all | ||
|---|---|---|
Brand SKF | ||
Product Type Tapered Roller Bearing | ||
Inside Diameter 35mm | ||
Bore Type Cylindrical | ||
Cage Material Sheet Metal | ||
Standards/Approvals UNSPSC, RoHS, eClass | ||
Series 32307 B | ||
Limiting Speed 8500rpm | ||
Bearing Dynamic Load Rating 115kN | ||
Outside Diameter 80mm | ||
Number of Rows 1 | ||
Cup Width 25mm | ||
Static Load Rating 114kN | ||
Cone Width 31mm | ||
Race Type Cylindrical | ||
Bearing Type Taper Roller | ||
- COO (Country of Origin):
- DE
Omkar
The SKF Single row tapered roller bearings are designed to accommodate combined radial and axial loads and provide low friction during operation. The inner ring, with rollers and cage, can be mounted separately from the outer ring. These separable and interchangeable components facilitate mounting, dismounting and maintenance. By mounting one single row tapered roller bearing against another and applying a preload, a rigid bearing application can be achieved.
High radial and axial load carrying capacity
Accommodate axial loads in one direction
Low friction and long service life
Separable and interchangeable components
