SKF LM 29749/711/Q Taper Roller 38.1 mm ID Tapered Roller Bearing, 65.08 mm OD
- RS Stock No.:
- 461-615
- Mfr. Part No.:
- LM 29749/711/Q
- Brand:
- SKF
Subtotal (1 unit)*
£54.33
(exc. VAT)
£65.20
(inc. VAT)
FREE delivery for orders over £60.00
Stocked by manufacturer
- Ready to ship from 21 May 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £54.33 |
*price indicative
- RS Stock No.:
- 461-615
- Mfr. Part No.:
- LM 29749/711/Q
- Brand:
- SKF
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | SKF | |
| Product Type | Tapered Roller Bearing | |
| Inside Diameter | 38.1mm | |
| Bore Type | Cylindrical | |
| Cage Material | Sheet Metal | |
| Outside Diameter | 65.08mm | |
| Cup Width | 15.748mm | |
| Number of Rows | 1 | |
| Cone Width | 18.288mm | |
| Static Load Rating | 57kN | |
| Series | LM | |
| Standards/Approvals | RoHS, eClass, UNSPSC | |
| Bearing Dynamic Load Rating | 42.9kN | |
| Limiting Speed | 11000rpm | |
| Race Type | Cylindrical | |
| Bearing Type | Taper Roller | |
| Select all | ||
|---|---|---|
Brand SKF | ||
Product Type Tapered Roller Bearing | ||
Inside Diameter 38.1mm | ||
Bore Type Cylindrical | ||
Cage Material Sheet Metal | ||
Outside Diameter 65.08mm | ||
Cup Width 15.748mm | ||
Number of Rows 1 | ||
Cone Width 18.288mm | ||
Static Load Rating 57kN | ||
Series LM | ||
Standards/Approvals RoHS, eClass, UNSPSC | ||
Bearing Dynamic Load Rating 42.9kN | ||
Limiting Speed 11000rpm | ||
Race Type Cylindrical | ||
Bearing Type Taper Roller | ||
- COO (Country of Origin):
- IN
Akshay
The SKF Single row tapered roller bearings are designed to accommodate combined radial and axial loads and provide low friction during operation. The inner ring, with rollers and cage, can be mounted separately from the outer ring. These separable and interchangeable components facilitate mounting, dismounting and maintenance. By mounting one single row tapered roller bearing against another and applying a preload, a rigid bearing application can be achieved.
High radial and axial load carrying capacity
Accommodate axial loads in one direction
Low friction and long service life
Separable and interchangeable components
