SKF 320/32 X Taper Roller 32 mm ID Tapered Roller Bearing, 58 mm OD
- RS Stock No.:
- 461-241
- Mfr. Part No.:
- 320/32 X
- Brand:
- SKF
Subtotal (1 unit)*
£38.49
(exc. VAT)
£46.19
(inc. VAT)
FREE delivery for orders over £60.00
Stocked by manufacturer
- Ready to ship from 23 June 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £38.49 |
*price indicative
- RS Stock No.:
- 461-241
- Mfr. Part No.:
- 320/32 X
- Brand:
- SKF
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | SKF | |
| Product Type | Tapered Roller Bearing | |
| Inside Diameter | 32mm | |
| Bore Type | Cylindrical | |
| Cage Material | Sheet Metal | |
| Cone Width | 17mm | |
| Limiting Speed | 11000rpm | |
| Cup Width | 13mm | |
| Number of Rows | 1 | |
| Static Load Rating | 46.5kN | |
| Outside Diameter | 58mm | |
| Bearing Dynamic Load Rating | 45.1kN | |
| Standards/Approvals | UNSPSC, RoHS, eClass | |
| Race Type | Cylindrical | |
| Bearing Type | Taper Roller | |
| Select all | ||
|---|---|---|
Brand SKF | ||
Product Type Tapered Roller Bearing | ||
Inside Diameter 32mm | ||
Bore Type Cylindrical | ||
Cage Material Sheet Metal | ||
Cone Width 17mm | ||
Limiting Speed 11000rpm | ||
Cup Width 13mm | ||
Number of Rows 1 | ||
Static Load Rating 46.5kN | ||
Outside Diameter 58mm | ||
Bearing Dynamic Load Rating 45.1kN | ||
Standards/Approvals UNSPSC, RoHS, eClass | ||
Race Type Cylindrical | ||
Bearing Type Taper Roller | ||
Omkar
The SKF Single row tapered roller bearings are designed to accommodate combined radial and axial loads and provide low friction during operation. The inner ring, with rollers and cage, can be mounted separately from the outer ring. These separable and interchangeable components facilitate mounting, dismounting and maintenance. By mounting one single row tapered roller bearing against another and applying a preload, a rigid bearing application can be achieved.
High radial and axial load carrying capacity
Accommodate axial loads in one direction
Low friction and long service life
Separable and interchangeable components
