FAG 22217-E1A-XL-M Cylindrical 85 mm ID Spherical Roller Bearing, 150 mm OD
- RS Stock No.:
- 312-466
- Mfr. Part No.:
- 22217-E1A-XL-M
- Brand:
- FAG
Subtotal (1 unit)*
£296.63
(exc. VAT)
£355.96
(inc. VAT)
FREE delivery for orders over £60.00
Stocked by manufacturer
- Ready to ship from 25 June 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £296.63 |
*price indicative
Better World
Our Better World range features products that make it easy for you to make a greener product choice you can trust. Click here to find out more.
- RS Stock No.:
- 312-466
- Mfr. Part No.:
- 22217-E1A-XL-M
- Brand:
- FAG
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | FAG | |
| Product Type | Spherical Roller Bearing | |
| Inside Diameter | 85mm | |
| Race Width | 36mm | |
| Bore Type | Cylindrical | |
| Cage Material | Brass | |
| Limiting Speed | 5700rpm | |
| Standards/Approvals | No | |
| Dynamic Load Rating | 305000N | |
| Outside Diameter | 150mm | |
| Internal Clearance | CN | |
| Static Load Rating | 325000N | |
| Number of Rows | 2 | |
| Bearing Material | Steel | |
| Series | 222..-E1A-XL-M | |
| Better World Claim | Extended Product Life, Saves Energy | |
| Better World Product | Yes | |
| Select all | ||
|---|---|---|
Brand FAG | ||
Product Type Spherical Roller Bearing | ||
Inside Diameter 85mm | ||
Race Width 36mm | ||
Bore Type Cylindrical | ||
Cage Material Brass | ||
Limiting Speed 5700rpm | ||
Standards/Approvals No | ||
Dynamic Load Rating 305000N | ||
Outside Diameter 150mm | ||
Internal Clearance CN | ||
Static Load Rating 325000N | ||
Number of Rows 2 | ||
Bearing Material Steel | ||
Series 222..-E1A-XL-M | ||
Better World Claim Extended Product Life, Saves Energy | ||
Better World Product Yes | ||
RoHS Status: Exempt
- COO (Country of Origin):
- US
The FAG Spherical Roller Bearing is designed to tackle high radial loads while accommodating axial displacement in both directions. With an innovative design featuring a brass cage and optimal internal clearance, it ensures reliable performance under demanding conditions. Its robust construction offers exceptional resistance to fatigue, making it an ideal choice for applications requiring durability.
Allows for accurate alignment reducing wear and tear
Provides extensive load ratings for various applications
Designed to minimise operational noise and vibration
