FAG 22320-E1A-XL-MA-T41A Cylindrical 100 mm ID Roller Bearing, 215 mm OD
- RS Stock No.:
- 311-147
- Mfr. Part No.:
- 22320-E1A-XL-MA-T41A
- Brand:
- FAG
Subtotal (1 unit)*
£896.37
(exc. VAT)
£1,075.64
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 08 April 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £896.37 |
*price indicative
- RS Stock No.:
- 311-147
- Mfr. Part No.:
- 22320-E1A-XL-MA-T41A
- Brand:
- FAG
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | FAG | |
| Product Type | Roller Bearing | |
| Inside Diameter | 100 mm | |
| Race Width | 73mm | |
| Bore Type | Cylindrical | |
| Cage Material | Solid Brass | |
| Static Load Rating | 920000N | |
| Series | 223..-E1A-XL-MA- T41A | |
| Internal Clearance | C4 | |
| Outside Diameter | 215 mm | |
| Number of Rows | 2 | |
| Standards/Approvals | No | |
| Limiting Speed | 3300rpm | |
| Bearing Material | Steel | |
| Dynamic Load Rating | 810000N | |
| Select all | ||
|---|---|---|
Brand FAG | ||
Product Type Roller Bearing | ||
Inside Diameter 100 mm | ||
Race Width 73mm | ||
Bore Type Cylindrical | ||
Cage Material Solid Brass | ||
Static Load Rating 920000N | ||
Series 223..-E1A-XL-MA- T41A | ||
Internal Clearance C4 | ||
Outside Diameter 215 mm | ||
Number of Rows 2 | ||
Standards/Approvals No | ||
Limiting Speed 3300rpm | ||
Bearing Material Steel | ||
Dynamic Load Rating 810000N | ||
RoHS Status: Exempt
The FAG Spherical Roller Bearing is engineered for demanding applications and offers exceptional performance in high-load environments. Designed with a symmetrical two outer ribs configuration, it ensures improved stability and reliability under dynamic loads. The robust construction features a solid brass cage that enhances durability, while the uniquely tailored internal clearance allows it to operate effectively in conditions of vibration, such as in vibrating screens.
Designed for dynamic load capacity ensuring safety under higher loads
Symmetrical design promotes stability during operation
Lightweight yet robust aiding in efficient machinery operation
