Sensata / Cynergy3 Panel Reed Relay, 24 V dc Coil, SPNC, 7000 V dc Max, 2 A Max, 925 Ω
- RS Stock No.:
- 511-1357
- Mfr. Part No.:
- DBT72410
- Brand:
- Sensata / Cynergy3
Bulk discount available
Subtotal (1 unit)*
£53.47
(exc. VAT)
£64.16
(inc. VAT)
FREE delivery for orders over £60.00
Limited stock
- Plus 61 left, shipping from 27 April 2026
- Plus 1,111 left, shipping from 27 April 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 - 24 | £53.47 |
| 25 - 99 | £50.90 |
| 100 + | £47.16 |
*price indicative
- RS Stock No.:
- 511-1357
- Mfr. Part No.:
- DBT72410
- Brand:
- Sensata / Cynergy3
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Sensata / Cynergy3 | |
| Product Type | Reed Relay | |
| Contact Configuration | SPNC | |
| Mount Type | Panel | |
| Coil Power | 50W | |
| Coil Resistance | 925Ω | |
| Terminal Type | Solder | |
| Switching Power | 50W | |
| Operating Time | 2ms | |
| Minimum Operating Temperature | -20°C | |
| Maximum Operating Temperature | 70°C | |
| Series | DBT | |
| Standards/Approvals | UR | |
| Length | 60mm | |
| Height | 18.5mm | |
| Isolation Coil To Contact | 17kV ac/dc | |
| Contact Resistance | 250mΩ | |
| Latching | No | |
| Select all | ||
|---|---|---|
Brand Sensata / Cynergy3 | ||
Product Type Reed Relay | ||
Contact Configuration SPNC | ||
Mount Type Panel | ||
Coil Power 50W | ||
Coil Resistance 925Ω | ||
Terminal Type Solder | ||
Switching Power 50W | ||
Operating Time 2ms | ||
Minimum Operating Temperature -20°C | ||
Maximum Operating Temperature 70°C | ||
Series DBT | ||
Standards/Approvals UR | ||
Length 60mm | ||
Height 18.5mm | ||
Isolation Coil To Contact 17kV ac/dc | ||
Contact Resistance 250mΩ | ||
Latching No | ||
- COO (Country of Origin):
- CN
Sensata Cynergy3 Reed Relay, SPNC, 1m - D Series - DBT72410
This Sensata Cynergy3 reed relay directs the electromagnet in a high-voltage reed switch. You can use it with switches of up to 24 volts on a direct current (DC), making it suitable for applications such as cardiac defibrillators, Triac trigger devices and high-voltage power supplies. The nylon studs connect to industry-standard circuits to create an airtight seal that stops dust from getting in. This unit offers low-power operation, making it an energy-efficient option.
Features & Benefits
• Mounts on a panel or printed circuit board (PCB) to suit your application
• High voltage connections via flying leads, solder turret (wire wrap), or 1/4" spade terminals for flexible installation
• Low contact resistance so contact interface isn't disrupted or melted under high power
Can this relay withstand harsh environments?
The relay has a wide operating temperature range of -20°C to +70°C, so you can use it in demanding environments where extremes of cold and heat are likely.
How long will this relay last?
The relay has an approximate lifespan of 1,000,000 electrical cycles so you can be confident it's a long-lasting option.
