Eaton RCD, 25A, 2 Pole, 500mA, Type AC
- RS Stock No.:
- 922-8604
- Mfr. Part No.:
- 235393 PFIM-25/2/05-MW
- Brand:
- Eaton
Subtotal (1 unit)*
£126.07
(exc. VAT)
£151.28
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- 999,999,999 unit(s) shipping from 12 January 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £126.07 |
*price indicative
- RS Stock No.:
- 922-8604
- Mfr. Part No.:
- 235393 PFIM-25/2/05-MW
- Brand:
- Eaton
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Eaton | |
| Circuit Breaker Type | RCD | |
| Current Rating | 25A | |
| Number of Poles | 2 | |
| Range | PFIM | |
| Trip Sensitivity | 500mA | |
| Tripping Characteristics | Type AC | |
| Reset Actuator Type | Toggle Switch | |
| Rated AC Voltage | 230, 400V | |
| Mounting Style | DIN Rail Mount | |
| Break Time | Instantaneous | |
| Overall Width | 65.5mm | |
| Overall Depth | 80mm | |
| Overall Dimensions | 35 x 65.5 x 80mm | |
| Terminal Contact Type | Screw | |
| Overall Length | 35mm | |
Select all | ||
|---|---|---|
Brand Eaton | ||
Circuit Breaker Type RCD | ||
Current Rating 25A | ||
Number of Poles 2 | ||
Range PFIM | ||
Trip Sensitivity 500mA | ||
Tripping Characteristics Type AC | ||
Reset Actuator Type Toggle Switch | ||
Rated AC Voltage 230, 400V | ||
Mounting Style DIN Rail Mount | ||
Break Time Instantaneous | ||
Overall Width 65.5mm | ||
Overall Depth 80mm | ||
Overall Dimensions 35 x 65.5 x 80mm | ||
Terminal Contact Type Screw | ||
Overall Length 35mm | ||
- COO (Country of Origin):
- RO
PFIM Series
Professional range of Eaton compact residual current devices from the PFIM series. Each device incorporates a real contact position indictor. Ideal for fault current/residual current protection and extra protection in a wide range of application. Various tripping current ratings are available.
Note
Eaton formerly known as Moeller
