Eaton PFIM Series Residual Current Device, 16A, 2-Pole, 10 mA, Type AC, 16 A 400V ac
- RS Stock No.:
- 922-8591
- Mfr. Part No.:
- 235389 PFIM-16/2/001-MW
- Brand:
- Eaton
Subtotal (1 unit)*
£137.72
(exc. VAT)
£165.26
(inc. VAT)
FREE delivery for orders over £60.00
In Stock
- 5 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £137.72 |
*price indicative
- RS Stock No.:
- 922-8591
- Mfr. Part No.:
- 235389 PFIM-16/2/001-MW
- Brand:
- Eaton
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Eaton | |
| Product Type | Residual Current Device | |
| Current Rating | 16A | |
| Number of Poles | 2 | |
| Series | PFIM | |
| Range | PFIM | |
| Trip Sensitivity | 10mA | |
| Mount Type | DIN Rail | |
| Tripping Characteristics | Type AC | |
| Terminal Type | Screw | |
| Standards/Approvals | IEC/EN 61008 | |
| Depth | 80mm | |
| Width | 35mm | |
| Height | 80mm | |
| Breaking Capacity | 16A | |
| Application | Industrial | |
| Break Time | Instantaneous | |
| Rated AC Voltage | 400V ac | |
| Tripping Mechanism | Electromagnetic | |
| Reset Actuator Type | Toggle Switch | |
| Select all | ||
|---|---|---|
Brand Eaton | ||
Product Type Residual Current Device | ||
Current Rating 16A | ||
Number of Poles 2 | ||
Series PFIM | ||
Range PFIM | ||
Trip Sensitivity 10mA | ||
Mount Type DIN Rail | ||
Tripping Characteristics Type AC | ||
Terminal Type Screw | ||
Standards/Approvals IEC/EN 61008 | ||
Depth 80mm | ||
Width 35mm | ||
Height 80mm | ||
Breaking Capacity 16A | ||
Application Industrial | ||
Break Time Instantaneous | ||
Rated AC Voltage 400V ac | ||
Tripping Mechanism Electromagnetic | ||
Reset Actuator Type Toggle Switch | ||
- COO (Country of Origin):
- RO
PFIM Series
Professional range of Eaton compact residual current devices from the PFIM series. Each device incorporates a real contact position indictor. Ideal for fault current/residual current protection and extra protection in a wide range of application. Various tripping current ratings are available.
Note
Eaton formerly known as Moeller
