Schneider Electric Acti9 Series Residual Current Circuit Breaker, 25A, 2-Pole, 300 mA, Type AC, 500 A 240V ac

View all RCCBs

Subtotal (1 unit)*

£146.21

(exc. VAT)

£175.45

(inc. VAT)

Add to Basket
Select or type quantity
In Stock
  • 2 unit(s) ready to ship from another location
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units
Per unit
1 +£146.21

*price indicative

Better World

Our Better World range features products that make it easy for you to make a greener product choice you can trust. Click here to find out more.

RS Stock No.:
238-3459
Mfr. Part No.:
A9R56225
Brand:
Schneider Electric
Find similar products by selecting one or more attributes.
Select all

Brand

Schneider Electric

Product Type

Residual Current Circuit Breaker

Current Rating

25A

Number of Poles

2

Series

Acti9

Range

Acti9

Trip Sensitivity

300mA

Tripping Characteristics

Type AC

Mount Type

DIN Rail

Terminal Type

Screw

Standards/Approvals

EN/IEC 61008-1

Width

36mm

Height

85mm

Depth

69mm

Better World Product

Yes

Breaking Capacity

500A

Application

Residential, Industrial

Reset Actuator Type

Toggle Switch

Rated AC Voltage

240V ac

Earth Leakage Protection Type

AC

Break Time

Instantaneous

COO (Country of Origin):
IN
The Schneider Electric Acti9 series residual current circuit breaker has instantaneous earth-leakage protection time delay with sensitivity of 300 mA. It is toggle control type with ON/OFF & trip indicator. Relative humidity of this type of circuit breaker is 95 % at 55 °C. These RCCBs are compliant with standards such as EN/IEC 61008-1.

Impulse withstand voltage is 4 kV

Clip-on mounting mode

Electrical durability of 20000 cycles

Ambient air temperature for operation is around -25 to 70 °C

Padlockable, providing extra protection

Schneider Green premium classed product
