Siemens SENTRON Series Residual Current Circuit Breaker, 16 A, 2-Pole, 30 mA, Type AC, 10 kA 230 V ac
- RS Stock No.:
- 231-8386
- Mfr. Part No.:
- 5SV4311-0
- Brand:
- Siemens
Subtotal (1 unit)*
£115.61
(exc. VAT)
£138.73
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 30 March 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £115.61 |
*price indicative
- RS Stock No.:
- 231-8386
- Mfr. Part No.:
- 5SV4311-0
- Brand:
- Siemens
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Siemens | |
| Product Type | Residual Current Circuit Breaker | |
| Current Rating | 16 A | |
| Number of Poles | 2 | |
| Series | SENTRON | |
| Range | SENTRON | |
| Trip Sensitivity | 30mA | |
| Tripping Characteristics | Type AC | |
| Mount Type | DIN Rail | |
| Standards/Approvals | VDE, CE, EAC, UKCA | |
| Terminal Type | Screw | |
| Depth | 70mm | |
| Width | 72 mm | |
| Height | 90mm | |
| Breaking Capacity | 10kA | |
| Rated AC Voltage | 230 V ac | |
| Earth Leakage Protection Type | AC | |
| Break Time | Instantaneous | |
| Reset Actuator Type | Toggle Switch | |
| Select all | ||
|---|---|---|
Brand Siemens | ||
Product Type Residual Current Circuit Breaker | ||
Current Rating 16 A | ||
Number of Poles 2 | ||
Series SENTRON | ||
Range SENTRON | ||
Trip Sensitivity 30mA | ||
Tripping Characteristics Type AC | ||
Mount Type DIN Rail | ||
Standards/Approvals VDE, CE, EAC, UKCA | ||
Terminal Type Screw | ||
Depth 70mm | ||
Width 72 mm | ||
Height 90mm | ||
Breaking Capacity 10kA | ||
Rated AC Voltage 230 V ac | ||
Earth Leakage Protection Type AC | ||
Break Time Instantaneous | ||
Reset Actuator Type Toggle Switch | ||
- COO (Country of Origin):
- DE
The Siemens 5SV4 series is the residual current operated circuit breaker having 2 pole. The tripping characteristic class of this residual current operated circuit breaker is type AC and its rated current is 16A. The tripping fault current of circuit breaker is 30 mA.
IP degree of protection is IP20
Ambient temperature range is -25 °C to 45 °C
Shock resistance
Fastening method is DIN rail
