Siemens SENTRON Series Residual Current Circuit Breaker, 25 A, 2-Pole, 30 mA, Type B, 10 kA 230 V ac
- RS Stock No.:
- 231-8374
- Mfr. Part No.:
- 5SV3322-4
- Brand:
- Siemens
Subtotal (1 unit)*
£445.24
(exc. VAT)
£534.29
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 09 April 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £445.24 |
*price indicative
- RS Stock No.:
- 231-8374
- Mfr. Part No.:
- 5SV3322-4
- Brand:
- Siemens
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Siemens | |
| Product Type | Residual Current Circuit Breaker | |
| Current Rating | 25 A | |
| Number of Poles | 2 | |
| Series | SENTRON | |
| Range | SENTRON | |
| Trip Sensitivity | 30mA | |
| Tripping Characteristics | Type B | |
| Mount Type | DIN Rail | |
| Standards/Approvals | VDE, CE, EAC, UKCA | |
| Terminal Type | Screw | |
| Depth | 70mm | |
| Height | 90mm | |
| Width | 72 mm | |
| Breaking Capacity | 10kA | |
| Break Time | Instantaneous | |
| Reset Actuator Type | Toggle Switch | |
| Earth Leakage Protection Type | Type B | |
| Rated AC Voltage | 230 V ac | |
| Select all | ||
|---|---|---|
Brand Siemens | ||
Product Type Residual Current Circuit Breaker | ||
Current Rating 25 A | ||
Number of Poles 2 | ||
Series SENTRON | ||
Range SENTRON | ||
Trip Sensitivity 30mA | ||
Tripping Characteristics Type B | ||
Mount Type DIN Rail | ||
Standards/Approvals VDE, CE, EAC, UKCA | ||
Terminal Type Screw | ||
Depth 70mm | ||
Height 90mm | ||
Width 72 mm | ||
Breaking Capacity 10kA | ||
Break Time Instantaneous | ||
Reset Actuator Type Toggle Switch | ||
Earth Leakage Protection Type Type B | ||
Rated AC Voltage 230 V ac | ||
- COO (Country of Origin):
- DE
The Siemens 5SV3 series is the residual current operated circuit breaker having 2 pole. The tripping characteristic class of this residual current operated circuit breaker is type B and its rated current is 25A. The tripping fault current of circuit breaker is 30 mA.
IP degree of protection is IP20
Ambient temperature range is -25 °C to 45 °C
Shock resistance
Fastening method is DIN rail
