ABB F200 Series Residual Current Circuit Breaker, 40 A, 2-Pole, 500 mA, Type A, 0.5 A 230 V ac
- RS Stock No.:
- 225-6112
- Mfr. Part No.:
- 2CSF202101R4400 F202 A-40/0.5
- Brand:
- ABB
Subtotal (1 unit)*
£171.94
(exc. VAT)
£206.33
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 2 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £171.94 |
*price indicative
- RS Stock No.:
- 225-6112
- Mfr. Part No.:
- 2CSF202101R4400 F202 A-40/0.5
- Brand:
- ABB
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | ABB | |
| Product Type | Residual Current Circuit Breaker | |
| Number of Poles | 2 | |
| Range | F200 | |
| Series | F200 | |
| Trip Sensitivity | 500mA | |
| Mount Type | DIN Rail | |
| Tripping Characteristics | Type A | |
| Standards/Approvals | CE, RoHS | |
| Terminal Type | Screw | |
| Depth | 69mm | |
| Height | 85mm | |
| Breaking Capacity | 0.5A | |
| Reset Actuator Type | Toggle Switch | |
| Earth Leakage Protection Type | Type A | |
| Break Time | Instantaneous | |
| Select all | ||
|---|---|---|
Brand ABB | ||
Product Type Residual Current Circuit Breaker | ||
Number of Poles 2 | ||
Range F200 | ||
Series F200 | ||
Trip Sensitivity 500mA | ||
Mount Type DIN Rail | ||
Tripping Characteristics Type A | ||
Standards/Approvals CE, RoHS | ||
Terminal Type Screw | ||
Depth 69mm | ||
Height 85mm | ||
Breaking Capacity 0.5A | ||
Reset Actuator Type Toggle Switch | ||
Earth Leakage Protection Type Type A | ||
Break Time Instantaneous | ||
The ABB F200 series residual current circuit breaker assures protection to people and installations against fault current to earth. It detects pulsating current with DC component. It is mainly used for general applications such as industrial, household and commercial.
Degree of protection IP2X
Operating temperature range of -25 to +55 °C
Optimum frequency range of 50 to 60 Hz
DIN rail mounting
