Eaton PDIM Series Residual Current Circuit Breaker, 100 A, 4-Pole, 1 mA, Type A 400 V ac

RS Stock No.:: 231-924
Mfr. Part No.:: 111761 PDIM-100/4
Brand:: Eaton

Eaton PDIM Series Residual Current Circuit Breaker, 100 A, 4-Pole, 1 mA, Type A 400 V ac

Subtotal (1 unit)*

£404.33

(exc. VAT)

£485.20

(inc. VAT)

Stock information currently inaccessible - Please check back later

Units	Per unit
1 +	£404.33

*price indicative

RS Stock No.:: 231-924
Mfr. Part No.:: 111761 PDIM-100/4
Brand:: Eaton

Specifications

Technical Reference

Legislation and Compliance

Product Details

Find similar products by selecting one or more attributes.

Select all	Attribute	Value
	Brand	Eaton
	Product Type	Residual Current Circuit Breaker
	Current Rating	100 A
	Number of Poles	4
	Range	xPole
	Series	PDIM
	Trip Sensitivity	1mA
	Tripping Characteristics	Type A
	Mount Type	DIN Rail
	Terminal Type	Twin-Purpose Terminal
	Standards/Approvals	DINEN 600, RoHS
	Depth	80mm
	Width	70 mm
	Height	65.5mm
	Break Time	Non-Delayed
	Rated AC Voltage	400 V ac

	Select all
	Brand Eaton
	Product Type Residual Current Circuit Breaker
	Current Rating 100 A
	Number of Poles 4
	Range xPole
	Series PDIM
	Trip Sensitivity 1mA
	Tripping Characteristics Type A
	Mount Type DIN Rail
	Terminal Type Twin-Purpose Terminal
	Standards/Approvals DINEN 600, RoHS
	Depth 80mm
	Width 70 mm
	Height 65.5mm
	Break Time Non-Delayed
	Rated AC Voltage 400 V ac

Datasheet - 111761 PDIM-100/4

COO (Country of Origin):: CZ

The Eaton cutting-edge residual current circuit-breaker designed specifically for industrial and advanced commercial applications. It boasts an impressive 100A capacity and operates with four poles, ensuring robust performance while safeguarding electrical installations from faults. Engineered with versatility in mind, this circuit-breaker is equipped to handle various leakage current settings, adjustable from 0.03A to 1A, providing tailored protection for different operational needs. Its compact design and efficient heat dissipation make it suitable for modern switchgear, meeting stringent environmental and compliance standards. With features aimed at enhancing user-friendliness and reliability, the PDIM-100/4 serves as an essential component for effective electrical safety management.

Offers adjustable fault current settings for tailored protection

Built for easy installation on DIN rails, enhancing versatility

Equipped with a leak detection mechanism to mitigate electrical hazards

Designed to withstand a wide range of ambient operating temperatures

Ensures reliable electromagnetic compatibility for stable performance

Features a robust degree of protection, enhancing durability in challenging environments

Built with interlocking device functionality to provide added safety

Supports multi-wired and solid-core connector cross-sections for flexibility

Eaton PDIM Series Residual Current Circuit Breaker, 100 A, 4-Pole, 1 mA, Type A 400 V ac
