Siemens RCBO, 25A Current Rating, 2P Poles, 300mA Trip Sensitivity, Type B, Sentron Range
- RS Stock No.:
- 225-8795
- Mfr. Part No.:
- 5SU1656-6KK25
- Brand:
- Siemens
Subtotal (1 unit)*
£123.56
(exc. VAT)
£148.27
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 01 December 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £123.56 |
*price indicative
Better World
Our Better World range features products that make it easy for you to make a greener product choice you can trust. Click here to find out more.
- RS Stock No.:
- 225-8795
- Mfr. Part No.:
- 5SU1656-6KK25
- Brand:
- Siemens
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Siemens | |
| Current Rating | 25A | |
| Range | Sentron | |
| Number of Poles | 2 | |
| Circuit Breaker Type | RCBO | |
| Trip Sensitivity | 300mA | |
| Series | 5SU1 | |
| Tripping Characteristics | Type B | |
| Rated AC Voltage | 240V | |
| Better World Product | Yes | |
| Better World Claim | Extended product life | |
| Overall Length | 90mm | |
| Standards Met | CE | |
| Overall Dimensions | 77 x 90 x 36mm | |
| Breaking Capacity at Maximum Voltage Rating | 6 kA | |
| Overall Depth | 77mm | |
| Overall Width | 36mm | |
Select all | ||
|---|---|---|
Brand Siemens | ||
Current Rating 25A | ||
Range Sentron | ||
Number of Poles 2 | ||
Circuit Breaker Type RCBO | ||
Trip Sensitivity 300mA | ||
Series 5SU1 | ||
Tripping Characteristics Type B | ||
Rated AC Voltage 240V | ||
Better World Product Yes | ||
Better World Claim Extended product life | ||
Overall Length 90mm | ||
Standards Met CE | ||
Overall Dimensions 77 x 90 x 36mm | ||
Breaking Capacity at Maximum Voltage Rating 6 kA | ||
Overall Depth 77mm | ||
Overall Width 36mm | ||
- COO (Country of Origin):
- RO
Siemens RCBO, Type-B Tripping, 10,000 Switching Cycles - SENTRON Series - 5SU1656-6KK25
Get triple protection against electrical hazards in your circuit with this RCBO from Siemens. It combines safety against short circuits, current overload and earth leakage currents into one handy device. The unit constantly monitors power conditions and quickly cuts off the supply to downstream devices when it senses a hazard. Its type-B characteristics mean it trips when it receives between five and ten times its rated current of 25A. This means you can count on high sensitivity to glitches. In the event of a phase imbalance, the breaker directs the dangerous current to the ground, shielding users and equipment from electric shocks. You can use a unit like this to protect your lighting fixtures and control panel.
Features & Benefits
• Durable option with surge current resistance up to 1kA
• Can be mounted in any position for versatile assembly
• Integrated touch protection makes it safe to handle
• Accepts a power supply at the top or bottom for flexible electrical connection
• Can be mounted in any position for versatile assembly
• Integrated touch protection makes it safe to handle
• Accepts a power supply at the top or bottom for flexible electrical connection
How do I reset this RCBO?
You can quickly reset this device after it trips by flipping its front-facing toggle switch and returning it to its original position.
