Siemens RCBO, 13A Current Rating, 2P Poles, 10mA Trip Sensitivity, SENTRON Range
- RS Stock No.:
- 211-9597
- Distrelec Article No.:
- 301-37-485
- Mfr. Part No.:
- 5SU1154-7KK13
- Brand:
- Siemens
Subtotal (1 unit)*
£142.54
(exc. VAT)
£171.05
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 9 unit(s) ready to ship from another location
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £142.54 |
*price indicative
Better World
Our Better World range features products that make it easy for you to make a greener product choice you can trust. Click here to find out more.
- RS Stock No.:
- 211-9597
- Distrelec Article No.:
- 301-37-485
- Mfr. Part No.:
- 5SU1154-7KK13
- Brand:
- Siemens
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Siemens | |
| Current Rating | 13A | |
| Number of Poles | 2 | |
| Range | SENTRON | |
| Trip Sensitivity | 10mA | |
| Series | 5SU1 | |
| Rated AC Voltage | 230V | |
| Better World Product | Yes | |
| Better World Claim | Extended product life | |
| Overall Width | 36mm | |
| Overall Dimensions | 77 x 36 x 90mm | |
| Overall Depth | 77mm | |
Select all | ||
|---|---|---|
Brand Siemens | ||
Current Rating 13A | ||
Number of Poles 2 | ||
Range SENTRON | ||
Trip Sensitivity 10mA | ||
Series 5SU1 | ||
Rated AC Voltage 230V | ||
Better World Product Yes | ||
Better World Claim Extended product life | ||
Overall Width 36mm | ||
Overall Dimensions 77 x 36 x 90mm | ||
Overall Depth 77mm | ||
- COO (Country of Origin):
- RO
The Siemens RCBO has breaking capacity is 10 kA number of poles are 1P+N and type A, tripping residual current is 10 mA, operating current is 13 A, supply voltage is 230 V. RCBOs for combined short-circuit protection and anti-contact protection. An important element of the SENTRON protective devices for electrical installations, the patented RCBOs from Siemens allow combined personnel, fire and cable protection in just one device. Siemens offers a comprehensive portfolio of protection, switching, measuring and monitoring devices, distribution systems as well as switches and sockets for safe and efficient electrical infrastructure in buildings and industry.
Protection class IP IP20 if the distribution board is installed, with connected conductors
neutral conductor switching
Touch protection
neutral conductor switching
Touch protection
