ABB RCBO, 16A Current Rating, 1P+N Poles, 30mA Trip Sensitivity, System Pro M Compact Range
- RS Stock No.:
- 201-6860
- Mfr. Part No.:
- 2CSR255180R1167
- Brand:
- ABB
Available to back order for despatch 02/07/2024
Added
Price Each
£132.66
(exc. VAT)
£159.19
(inc. VAT)
| Units | Per unit |
| 1 + | £132.66 |
- RS Stock No.:
- 201-6860
- Mfr. Part No.:
- 2CSR255180R1167
- Brand:
- ABB
Technical Reference
Legislation and Compliance
Product Details
The ABB DS201 series 16A residual current circuit breaker mainly used for overload protection. It has two-modules width for the protection of end user single-phase circuits against overload and short-circuit current , protection against the effects of sinusoidal alternating earth fault current , direct contacts and indirect contacts.
Rated voltage 230-240V
Type of residual current is AC
Pollution degree is 2
Degree of protection for terminals IP20
Degree of protection for housing IP40
Type of residual current is AC
Pollution degree is 2
Degree of protection for terminals IP20
Degree of protection for housing IP40
Specifications
Attribute | Value |
|---|---|
| Current Rating | 16A |
| Number of Poles | 1P+N |
| Trip Sensitivity | 30mA |
| Range | System Pro M Compact |
| Circuit Breaker Type | RCBO |
| Series | DS201 |
| Mounting Style | DIN Rail Mount |
| Breaking Capacity at Maximum Voltage Rating | 6 kA |
