Siemens Residual Current Circuit Breaker with Overload Protection, 10 A Current Rating, 2-Pole, 30 mA Trip Sensitivity,

View all RCBOs

Subtotal (1 unit)*

£233.87

(exc. VAT)

£280.64

(inc. VAT)

Add to Basket
Select or type quantity
Orders below £50.00 (exc. VAT) cost £6.95.
In Stock
  • 8 unit(s) ready to ship from another location
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units
Per unit
1 +£233.87

*price indicative

Better World

Our Better World range features products that make it easy for you to make a greener product choice you can trust. Click here to find out more.

RS Stock No.:
196-3608
Mfr. Part No.:
5SU13531KK10
Brand:
Siemens
Find similar products by selecting one or more attributes.
Select all

Brand

Siemens

Product Type

Residual Current Circuit Breaker with Overload Protection

Current Rating

10 A

Range

SENTRON

Series

5SU1

Number of Poles

2

Trip Sensitivity

30mA

Tripping Characteristics

Type AC

Mount Type

DIN Rail

Rated AC Voltage

230 V ac

Earth Leakage Protection Type

AC

Height

90mm

Depth

77mm

Width

36 mm

Better World Claim

Extended Product Life

Better World Product

Yes

Standards/Approvals

CETerminal Contact Type

Reset Actuator Type

Toggle Switch

Breaking Capacity

4.5kA

COO (Country of Origin):
RO

Siemens 5SU1 Series RCBO, 10A Current Rating, 30mA Trip Sensitivity - 5SU13531KK10


This RCBO is a reliable type AC circuit breaker, offering essential protection in electrical installations. With a current rating of 10A and a maximum breaking capacity of 4.5kA, this 2-pole device is designed for rapid tripping in the event of a fault. It measures 35.4mm in width, 76.2mm in height, and has a depth of 90mm, making it ideal for DIN rail mounting.

Features & Benefits


• Instantaneous trip reduces potential electrical hazards

• 30mA trip sensitivity protects against earth faults

• Easy installation with screw terminal connections

• Halogen-free construction promotes safety and sustainability

Applications


• Implemented in residential and commercial electrical panels

• Utilised in automation systems requiring circuit protection

• Suitable for industrial machinery and equipment safeguarding

• Employed in complex electrical installations for enhanced safety

How does the tripping characteristic class C benefit electrical systems?


The class C tripping characteristic is suitable for applications with moderate inrush currents, allowing the device to withstand brief overloads without tripping, thus supporting system reliability.

What is the significance of having a 2-pole configuration?


The 2-pole configuration provides simultaneous protection for both live and neutral conductors, ensuring comprehensive safety in dual-phase electrical systems, preventing issues such as imbalances or overloads.

Can this device handle higher surge currents?


Yes, this RCBO has a surge current resistance of 1kA at a rise time of (8/20) μs, allowing it to withstand brief high current surges typically associated with fault conditions.
