Microchip PIC18F26Q43-E/STXVAO 1 PWM Controller, 32 MHz 5.5 V 28-Pin, VQFN

View all PWM

Subtotal (1 box of 546 units)*

£755.664

(exc. VAT)

£906.906

(inc. VAT)

Add to Basket
Select or type quantity
Orders below £50.00 (exc. VAT) cost £6.95.
Temporarily out of stock
  • Shipping from 02 April 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units
Per unit
Per Box*
546 +£1.384£755.66

*price indicative

RS Stock No.:
631-505
Mfr. Part No.:
PIC18F26Q43-E/STXVAO
Brand:
Microchip
Find similar products by selecting one or more attributes.
Select all

Brand

Microchip

Product Type

PWM Controller

Maximum Switching Frequency

32MHz

Supply Current

48μA

Output Voltage

1.024/4.096 V

Number of Outputs

1

Package Type

VQFN

Minimum Supply Voltage

1.8V

Pin Count

28

Maximum Supply Voltage

5.5V

Minimum Operating Temperature

-40°C

Maximum Operating Temperature

125°C

Series

PIC18-Q43

Standards/Approvals

No

Automotive Standard

No

COO (Country of Origin):
TH
The Microchip PIC18-Q43 microcontroller family features a 12-bit Analog-to-Digital Converter with Computation (ADCC) automating Capacitive Voltage Divider (CVD) techniques for advanced capacitive touch sensing, averaging, filtering, oversampling and threshold comparison. This family showcases a new 16-bit Pulse-Width Modulator (PWM) module which provides dual independent outputs on the same time base.

C Compiler optimized RISC architecture

127 level deep hardware stack

Low current power on reset

Configurable power up timer

Brown out reset

Low power BOR option

Windowed watchdog timer
