Banner OTC Series Illuminated Push Button Switch, Alternate, 30.2 mm Cutout, 30 V dc 250 V ac
- RS Stock No.:
- 861-4607
- Mfr. Part No.:
- OTC-1-YW
- Brand:
- Banner
Bulk discount available
View bulk pricing optionsSubtotal (1 unit)*
£19.19
(exc. VAT)
£23.03
(inc. VAT)
FREE delivery for orders over £60.00
Stocked by manufacturer
- Ready to ship from 26 October 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 - 4 | £19.19 |
| 5 - 9 | £18.82 |
| 10 + | £17.94 |
*price indicative
- RS Stock No.:
- 861-4607
- Mfr. Part No.:
- OTC-1-YW
- Brand:
- Banner
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Banner | |
| Switch Operation | Alternate | |
| Product Type | Push Button Switch | |
| Illuminated | Yes | |
| Panel Cutout Size | 30.2 mm | |
| Series | OTC | |
| Actuator Style | Button | |
| Minimum Operating Temperature | -20°C | |
| Contact AC Voltage | 250V ac | |
| Contact DC Voltage | 30V dc | |
| Switch Configuration | SPDT | |
| Maximum Operating Temperature | 50°C | |
| Switch Contact Current | 7A | |
| Standards/Approvals | OSHA, ANSI B11 | |
| Select all | ||
|---|---|---|
Brand Banner | ||
Switch Operation Alternate | ||
Product Type Push Button Switch | ||
Illuminated Yes | ||
Panel Cutout Size 30.2 mm | ||
Series OTC | ||
Actuator Style Button | ||
Minimum Operating Temperature -20°C | ||
Contact AC Voltage 250V ac | ||
Contact DC Voltage 30V dc | ||
Switch Configuration SPDT | ||
Maximum Operating Temperature 50°C | ||
Switch Contact Current 7A | ||
Standards/Approvals OSHA, ANSI B11 | ||
- COO (Country of Origin):
- CN
Opto Touch Switch
The Turck Banner OTB series of touch-activated photoelectric switches are designed to replace capacitive touch switches and mechanical push buttons.
The OTB series of touch button switches are highly resistant to EMI, RFI and ambient light interference.
Contact configuration SPDT 1 x N/O, 1 x N/C
LED indication of ’power on’ and ’output activated’
Black polysulfone (VALOX)housing, epoxy-encapsulated electronics, IP67
Switching current : 7A max. (resistive load)
Operating temperature range: -20 to +50 °C
'Mechanical life: Fifty million operations.
Ambient light immunity 120000 lux
Reduces the risk of repetitive strain injuries
Mounting M30 thread, nuts/washer included
Dimension (mm): 60 x 44 x 36 LWH (excluding threaded portion)
Zero Force & Opto Touch Switches
Actuated by sensors using patented Field Effect Technology which converts the touch of the operators hand into an electrical output. The two sensors have to be touched within 0.2 seconds of each other and can differentiate between a person's hand and most solid objects/substances, as well as resistance to accidental actuation via clothing, fluid, splashes etc.,There are built in diagnostic safeguards for power-up protection, foreign object intervention and film/deposit interference which all result in LED indication.
