RS PRO Illuminated Push Button Switch, Latching, Panel Mount, 22.2mm Cutout, DPST, Red LED, 250V ac, IP65
- RS Stock No.:
- 248-9200
- Brand:
- RS PRO
Bulk discount available
Subtotal (1 unit)*
£36.00
(exc. VAT)
£43.20
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 4 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
---|---|
1 - 9 | £36.00 |
10 - 99 | £34.92 |
100 + | £28.80 |
*price indicative
- RS Stock No.:
- 248-9200
- Brand:
- RS PRO
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | RS PRO | |
Switch Operation | Latching | |
Illuminated | Yes | |
Panel Cut Out Diameter | 22.2mm | |
Series | SW22S | |
Mounting Type | Panel Mount | |
Push Button Colour | Silver | |
Contact Configuration | DPST | |
Voltage Rating | 250V ac | |
Push Button Style | Round | |
LED Colour | Red | |
IP Rating | IP65 | |
Push Button Material | Stainless Steel | |
Contact Current Rating | 5 A @ 250 V ac | |
Contact Material | Silver Alloy | |
Case Colour | Natural | |
Manufacturer Part No. | SW22SSL316 | |
Contact AC Voltage Rating | 250V | |
Legend | Power | |
Minimum Operating Temperature | -40°C | |
Terminal Type | Screw | |
Maximum Operating Temperature | +80°C | |
Select all | ||
---|---|---|
Brand RS PRO | ||
Switch Operation Latching | ||
Illuminated Yes | ||
Panel Cut Out Diameter 22.2mm | ||
Series SW22S | ||
Mounting Type Panel Mount | ||
Push Button Colour Silver | ||
Contact Configuration DPST | ||
Voltage Rating 250V ac | ||
Push Button Style Round | ||
LED Colour Red | ||
IP Rating IP65 | ||
Push Button Material Stainless Steel | ||
Contact Current Rating 5 A @ 250 V ac | ||
Contact Material Silver Alloy | ||
Case Colour Natural | ||
Manufacturer Part No. SW22SSL316 | ||
Contact AC Voltage Rating 250V | ||
Legend Power | ||
Minimum Operating Temperature -40°C | ||
Terminal Type Screw | ||
Maximum Operating Temperature +80°C | ||
RoHS Status: Exempt
- COO (Country of Origin):
- CN
RS PRO Anti-Vandal Red Illuminated Power Legend Push Button Switch, 22.2mm
RS PROs high quality Stainless Steel anti vandal pushbutton is ideal for use in harsh conditions or public facing applications and is designed to withstand damage from physical attacks and repeated use.
Featuring an illuminated LED Power indictor, the RS PRO IP65 push button is panel mounted for easy and quick installation and is rated for water resistance and ingress protection making it suitable for use in internal and external applications.
Features and Benefits
- Power legend
- Stainless Steel push button
- Vandal resistant
- Panel mount installation
- Latching switch operation
- ≥1,000,000 operations
- ≥1,000 MΩ Insulation Resistance
- Screw terminals
Standards and Approvals: IP65, IK10
Why RS PRO?
RS PRO is our own brand range and brings you a wide range of high-quality, great value products offering you more choice. Trusted by engineers all over the world, every part of every RS PRO product has been rigorously tested against demanding industry standards; theyre only given the RS PRO Seal of Approval if were confident of their exceptional quality, which means you can be confident too.
Supplied with
1 x Switch, 1 x Hex Nut, 1 x O-Ring
