Fluke -13 psi to 600 psi Pressure Module, UKAS

RS Stock No.:: 533-914
Mfr. Part No.:: FLK-PMM-4000K
Brand:: Fluke

Fluke -13 psi to 600 psi Pressure Module, UKAS

Subtotal (1 unit)*

£2,691.00

(exc. VAT)

£3,229.20

(inc. VAT)

FREE delivery for orders over £60.00

In Stock

Plus 2 unit(s) shipping from 10 August 2026

Need more? Click ‘Check delivery dates’ to find extra stock and lead times.

Units	Per unit
1 +	£2,691.00

*price indicative

RS Stock No.:: 533-914
Mfr. Part No.:: FLK-PMM-4000K
Brand:: Fluke

Specifications

Technical Reference

Legislation and Compliance

Product Details

Find similar products by selecting one or more attributes.

Select all	Attribute	Value
	Brand	Fluke
	Maximum Pressure Measurement	600psi
	Battery Type	Rechargeable Lithium-ion
	Product Type	Pressure Module
	Minimum Pressure Measurement	-13psi
	Resolution	0.01 psi
	Pressure Port Type	Gauge
	Data Logging	No
	Current Loop Measurement	Yes
	Display Type	Graphic Colour
	Leak Testing	Yes
	Power Source	Lithium-ion Battery
	Weight	4.9kg
	Minimum Operating Temperature	-10°C
	Maximum Operating Temperature	50°C
	Width	215mm
	Standards/Approvals	IEC 62133, RoHS, UN 38.3, IEC 610101 (general)
	Length	100mm
	Height	290mm
	Hazardous Area Certification	IEC 62133
	Calibrated	UKAS
	Plug Type	USB, AC

	Select all
	Brand Fluke
	Maximum Pressure Measurement 600psi
	Battery Type Rechargeable Lithium-ion
	Product Type Pressure Module
	Minimum Pressure Measurement -13psi
	Resolution 0.01 psi
	Pressure Port Type Gauge
	Data Logging No
	Current Loop Measurement Yes
	Display Type Graphic Colour
	Leak Testing Yes
	Power Source Lithium-ion Battery
	Weight 4.9kg
	Minimum Operating Temperature -10°C
	Maximum Operating Temperature 50°C
	Width 215mm
	Standards/Approvals IEC 62133, RoHS, UN 38.3, IEC 610101 (general)
	Length 100mm
	Height 290mm
	Hazardous Area Certification IEC 62133
	Calibrated UKAS
	Plug Type USB, AC

Datasheet - FLK-PMM-4000K

COO (Country of Origin):: CN

Fluke Pressure Module, 600 psi Maximum Pressure Measurement, 0.01 psi Resolution - FLK-PMM-4000K

This pressure module is a portable instrument designed to measure gauge pressure across a wide range for field and workshop use. It operates from a rechargeable lithium‑ion battery and presents readings on a graphic colour display, supporting leak testing and current loop measurement for diagnostic and calibration tasks. The unit conforms to relevant safety and transport standards for battery‑powered devices, enabling use in routine pressure verification and maintenance workflows.

Features and Benefits:

• Resolution 0.01 psi enabling fine measurement discrimination
• Measurement span -13 to 600 psi covering vacuum to high positive pressures
• Rechargeable lithium‑ion battery for extended untethered operation
• Graphic colour display simplifying data interpretation on‑site
• Current loop measurement facilitating integration with control systems
• USB and AC plugs for versatile charging and data connectivity

Applications

• Suitable for pressure calibration in industrial plants
• Ideal for on‑site leak testing and system diagnosis
• Used with hydraulic and pneumatic gauge systems
• Can be used for commissioning pressure sensors in process control
• Suitable for portable field verification of instrumentation

What environmental temperatures can it tolerate during use?

It operates reliably between -10°C and 50°C, allowing deployment in typical outdoor and controlled indoor environments.

How portable is the instrument in terms of mass?

It weighs 4.9 kg, providing a balance between robustness and transportability for technicians.

What types of connections are provided for power and data?

It includes USB and AC plug options for charging and interfacing with external equipment.

Which certification or approvals does the device meet related to batteries?

It meets IEC 62133 and UN 38.3 requirements for safe lithium‑ion battery design and transport.
