Infineon Low Side 1, Low Side Speed TEMPFET BTS244Z 5-Pin, TO-263
- RS Stock No.:
- 229-1755
- Mfr. Part No.:
- BTS244ZE3062AATMA2
- Brand:
- Infineon
Subtotal (1 reel of 1000 units)*
£2,478.00
(exc. VAT)
£2,974.00
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 11 November 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Reel* |
|---|---|---|
| 1000 + | £2.478 | £2,478.00 |
*price indicative
- RS Stock No.:
- 229-1755
- Mfr. Part No.:
- BTS244ZE3062AATMA2
- Brand:
- Infineon
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Infineon | |
| Product Type | Speed TEMPFET BTS244Z | |
| Power Switch Topology | Low Side | |
| Power Switch Type | Low Side | |
| Switch On Resistance RdsOn | 18mΩ | |
| Number of Outputs | 5 | |
| Number of Inputs | 1 | |
| Power Rating | 170W | |
| Interface Type | Analogue | |
| Mount Type | Surface | |
| Package Type | TO-263 | |
| Pin Count | 5 | |
| Maximum Supply Voltage | 55V | |
| Minimum Operating Temperature | -40°C | |
| Operating Current | 26A | |
| Maximum Operating Temperature | 175°C | |
| Width | 15 mm | |
| Standards/Approvals | RoHS | |
| Length | 10mm | |
| Height | 4.4mm | |
| Series | BTS244Z | |
| Automotive Standard | AEC-Q | |
| Select all | ||
|---|---|---|
Brand Infineon | ||
Product Type Speed TEMPFET BTS244Z | ||
Power Switch Topology Low Side | ||
Power Switch Type Low Side | ||
Switch On Resistance RdsOn 18mΩ | ||
Number of Outputs 5 | ||
Number of Inputs 1 | ||
Power Rating 170W | ||
Interface Type Analogue | ||
Mount Type Surface | ||
Package Type TO-263 | ||
Pin Count 5 | ||
Maximum Supply Voltage 55V | ||
Minimum Operating Temperature -40°C | ||
Operating Current 26A | ||
Maximum Operating Temperature 175°C | ||
Width 15 mm | ||
Standards/Approvals RoHS | ||
Length 10mm | ||
Height 4.4mm | ||
Series BTS244Z | ||
Automotive Standard AEC-Q | ||
The Infineon low-side temperature switch has Thyristor characteristics and enhancement mode. It has fast switching up to 1 MHz and over temperature protection. It is n channel and analog driving possible.
It is RoHS compliant and AEC qualified
It is avalanche rated
It has high current pinning
