STMicroelectronics STEC01PURLow Side Power Switch IC 16-Pin, VFQFPN
- RS Stock No.:
- 203-3435
- Mfr. Part No.:
- STEC01PUR
- Brand:
- STMicroelectronics
460 In stock - FREE next working day delivery available
Added
Price Each (In a Pack of 5)
£1.51
(exc. VAT)
£1.81
(inc. VAT)
| Units | Per unit | Per Pack* |
| 5 - 45 | £1.51 | £7.55 |
| 50 - 95 | £1.278 | £6.39 |
| 100 - 245 | £0.876 | £4.38 |
| 250 - 995 | £0.856 | £4.28 |
| 1000 + | £0.832 | £4.16 |
| *price indicative | ||
- RS Stock No.:
- 203-3435
- Mfr. Part No.:
- STEC01PUR
- Brand:
- STMicroelectronics
Technical Reference
Legislation and Compliance
- COO (Country of Origin):
- CN
Product Details
The STMicroelectronics STEC01 is an integrated programmable 12 mO power switch managed by the timer based circuitry. It has 3 timers designed to interrupt the ground path of a power application after a maximum on-time and inhibits the restart of the platform during a cooling window. It has a has a continuous current capability up to 7 A through the internal power MOSFET. By using an external power transistor driven through GDRV pin, a higher current can be supported. As soon as the activity on the PWM pin stops, the device automatically enters idle mode, waiting for a new valid PWM signal to be applied, in case of a normal operation.
Input under voltage lockout
VFQFPN 3x3x0.9 16L, 0.5 mm pitch package type
Two programmable timers T1, T3 and one fixed timer T2
VFQFPN 3x3x0.9 16L, 0.5 mm pitch package type
Two programmable timers T1, T3 and one fixed timer T2
Specifications
Attribute | Value |
|---|---|
| Power Switch Topology | Low Side |
| Maximum Operating Supply Voltage | 5 V |
| Maximum Operating Current | 7A |
| Number of Outputs | 2 |
| Package Type | VFQFPN |
| Pin Count | 16 |
