Panasonic PCB Mount Latching Power Relay, 5V dc Coil, 8A Switching Current, DPST
- RS Stock No.:
- 815-5044
- Mfr. Part No.:
- DK2A-L2-5V
- Brand:
- Panasonic
98 In stock - FREE next working day delivery available
Added
Price Each
£9.81
(exc. VAT)
£11.77
(inc. VAT)
| Units | Per unit |
| 1 - 4 | £9.81 |
| 5 + | £9.32 |
- RS Stock No.:
- 815-5044
- Mfr. Part No.:
- DK2A-L2-5V
- Brand:
- Panasonic
Technical Reference
Legislation and Compliance
- COO (Country of Origin):
- TH
Product Details
DK Series Relay
These PCB mount miniature power relays have a high capacity, high sensitivity and high breakdown voltage. A sealed construction allows automatic washing. Typical applications include power switching, industrial machinery, PLC's, temperature controllers, timers and home appliances.
Compact with high capacity
High sensitivity: 200 mW nominal operating power
High surge withstanding, 10,000V between contact and coil
Sealed construction
Miniature size, H10 x W20 x D12.5 mm
High sensitivity: 200 mW nominal operating power
High surge withstanding, 10,000V between contact and coil
Sealed construction
Miniature size, H10 x W20 x D12.5 mm
Approvals
UL, CSA, TÜV
Specifications
Attribute | Value |
|---|---|
| Coil Voltage | 5V dc |
| Contact Configuration | DPST |
| Mounting Type | PCB Mount |
| Switching Current | 8A |
| Latching | Yes |
| Terminal Type | PCB Pin |
| Maximum Switching Voltage AC | 250V |
| Maximum Switching Voltage DC | 125V dc |
| Length | 20mm |
| Coil Resistance | 125Ω |
| Coil Power | 200mW |
| Height | 10mm |
| Life | 50000000 operations |
| Contact Material | Silver Alloy |
| Minimum Operating Temperature | -40°C |
| Maximum Operating Temperature | +65°C |
| Isolation Coil To Contact | 4kVrms |
| Depth | 15mm |
| Maximum Switching Power DC | 240 W |
| Maximum Switching Power AC | 2 kVA |
| Application | Power |
| Dimensions | 20 x 15 x 10mm |
