Panasonic PCB Mount Power Relay, 5V dc Coil, 8A Switching Current, SPST
- RS Stock No.:
- 811-3101
- Mfr. Part No.:
- ST1-DC5V-F
- Brand:
- Panasonic
Bulk discount available
Subtotal (1 unit)*
£9.43
(exc. VAT)
£11.32
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 53 unit(s) ready to ship
- Plus 1 unit(s) ready to ship from another location
- Plus 100 unit(s) shipping from 29 October 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 - 9 | £9.43 |
| 10 - 19 | £8.88 |
| 20 - 39 | £7.99 |
| 40 - 79 | £7.21 |
| 80 + | £6.47 |
*price indicative
- RS Stock No.:
- 811-3101
- Mfr. Part No.:
- ST1-DC5V-F
- Brand:
- Panasonic
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Panasonic | |
| Coil Voltage | 5V dc | |
| Contact Configuration | SPST | |
| Mounting Type | PCB Mount | |
| Switching Current | 8A | |
| Number of Poles | 1 | |
| Latching | No | |
| Maximum Switching Voltage AC | 380V | |
| Maximum Switching Voltage DC | 250V dc | |
| Length | 31mm | |
| Coil Resistance | 105Ω | |
| Coil Power | 240mW | |
| Contact Material | Silver Alloy | |
| Depth | 14mm | |
| Isolation Coil To Contact | 3.75kVrms | |
| Maximum Operating Temperature | +60°C | |
| Minimum Operating Temperature | -40°C | |
| Life | 100000 Operations | |
| Height | 11mm | |
| Maximum Switching Power AC | 3.04 kVA | |
| Maximum Switching Power DC | 150 W | |
| Application | General Purpose | |
Select all | ||
|---|---|---|
Brand Panasonic | ||
Coil Voltage 5V dc | ||
Contact Configuration SPST | ||
Mounting Type PCB Mount | ||
Switching Current 8A | ||
Number of Poles 1 | ||
Latching No | ||
Maximum Switching Voltage AC 380V | ||
Maximum Switching Voltage DC 250V dc | ||
Length 31mm | ||
Coil Resistance 105Ω | ||
Coil Power 240mW | ||
Contact Material Silver Alloy | ||
Depth 14mm | ||
Isolation Coil To Contact 3.75kVrms | ||
Maximum Operating Temperature +60°C | ||
Minimum Operating Temperature -40°C | ||
Life 100000 Operations | ||
Height 11mm | ||
Maximum Switching Power AC 3.04 kVA | ||
Maximum Switching Power DC 150 W | ||
Application General Purpose | ||
- COO (Country of Origin):
- JP
ST Series Relay
These PCB mount power relays are IC drivable and are suitable for inductive load switching. These PCB power relays also offer a high switching capability, high breakdown voltage amd improved stability. The sealed design enables automatic cleaning.
High breakdown voltage
High switching capability, can be used for Inductive lamp load switching
Small form factor, sensitive enough for direct IC-driving
Dimensions, H11x W14 x D31 mm
Sealed construction allows automatic washing
ST-PS relay socket available, see stk. no 103-6836
High switching capability, can be used for Inductive lamp load switching
Small form factor, sensitive enough for direct IC-driving
Dimensions, H11x W14 x D31 mm
Sealed construction allows automatic washing
ST-PS relay socket available, see stk. no 103-6836
Approvals
UL, CSA, VDE, SEV
