ABB Plug In Power Relay, 230V ac Coil, 6A Switching Current, SPDT
- RS Stock No.:
- 775-5142
- Mfr. Part No.:
- 1SVR405613R3100 CR-M230AC4L
- Brand:
- ABB
Bulk discount available
Subtotal (1 unit)*
£10.21
(exc. VAT)
£12.25
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- 87 unit(s) shipping from 07 November 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
---|---|
1 - 4 | £10.21 |
5 - 9 | £9.70 |
10 - 24 | £9.21 |
25 - 49 | £8.69 |
50 + | £8.16 |
*price indicative
- RS Stock No.:
- 775-5142
- Mfr. Part No.:
- 1SVR405613R3100 CR-M230AC4L
- Brand:
- ABB
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | ABB | |
Coil Voltage | 230V ac | |
Contact Configuration | SPDT | |
Mounting Type | Plug In | |
Switching Current | 6A | |
Series | CR-M | |
Terminal Type | Fork, Screw, Spring | |
Length | 21.2mm | |
Contact Material | Gold Plated | |
Minimum Operating Temperature | -40°C | |
Maximum Operating Temperature | +55°C | |
Height | 35.6mm | |
Depth | 27.5mm | |
Dimensions | 21.2 x 27.5 x 35.6mm | |
Select all | ||
---|---|---|
Brand ABB | ||
Coil Voltage 230V ac | ||
Contact Configuration SPDT | ||
Mounting Type Plug In | ||
Switching Current 6A | ||
Series CR-M | ||
Terminal Type Fork, Screw, Spring | ||
Length 21.2mm | ||
Contact Material Gold Plated | ||
Minimum Operating Temperature -40°C | ||
Maximum Operating Temperature +55°C | ||
Height 35.6mm | ||
Depth 27.5mm | ||
Dimensions 21.2 x 27.5 x 35.6mm | ||
ABB CR-M Series Power Relay, 230V AC Coil Voltage, 6A Switching Current - 1SVR405613R3100 CR-M230AC4L
This power relay is a high-performance device designed for various automation and electrical applications. Constructed by ABB, it boasts a compact size with dimensions of 21.2 x 27.5 x 35.6mm. The relay operates at a coil voltage of 230V AC and features a single-pole double-throw (SPDT) contact configuration, making it versatile for different wiring setups.
Features & Benefits
• Enhanced connectivity with fork, screw, and spring terminal types
• Operates efficiently with a switching current capacity of 6A
• Reliable performance across a wide temperature range of -40 °C to +55 °C
• Compliant with IEC standards for safety and reliability
• Gold-plated relay contacts ensure durability and low resistance
• Plug-in design simplifies installation and maintenance tasks
• Operates efficiently with a switching current capacity of 6A
• Reliable performance across a wide temperature range of -40 °C to +55 °C
• Compliant with IEC standards for safety and reliability
• Gold-plated relay contacts ensure durability and low resistance
• Plug-in design simplifies installation and maintenance tasks
Applications
• Utilised in industrial automation systems for control functions
• Suitable for electrical panels and machinery interfacing
• Effective in HVAC systems for temperature regulation
• Employed in lighting control circuits for enhanced efficiency
• Suitable for electrical panels and machinery interfacing
• Effective in HVAC systems for temperature regulation
• Employed in lighting control circuits for enhanced efficiency
What environmental conditions can this device withstand?
It operates effectively between -40 °C and +55 °C, making it suitable for harsh environments where temperature extremes are common.
How does the contact configuration impact performance?
The SPDT configuration allows for versatile functionality, enabling connections to multiple circuits or systems, providing flexibility in applications.
What terminal types are compatible with this relay?
The relay supports fork, screw, and spring terminals, allowing for various installation methods to suit specific project requirements.
What is the benefit of gold-plated contacts in this device?
Gold plating on the contacts minimises oxidation and provides reliable conductivity, enhancing the lifespan and overall performance of the relay.
Is this relay suitable for outdoor applications?
While it can handle a broad temperature range, any outdoor use should consider protection from moisture and dust, as these factors can impact its longevity and reliability.
