Finder PCB Mount Power Relay, 24V dc Coil, 30A Switching Current, SPST
- RS Stock No.:
- 749-5130
- Mfr. Part No.:
- 45.31.7.024.0310
- Brand:
- Finder
Save 34% when you buy 250 units
Subtotal (1 unit)*
£6.95
(exc. VAT)
£8.34
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 14 unit(s) ready to ship
- Plus 150 unit(s) ready to ship from another location
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
---|---|
1 - 24 | £6.95 |
25 - 49 | £6.13 |
50 - 99 | £5.92 |
100 - 249 | £5.43 |
250 + | £4.53 |
*price indicative
- RS Stock No.:
- 749-5130
- Mfr. Part No.:
- 45.31.7.024.0310
- Brand:
- Finder
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | Finder | |
Coil Voltage | 24V dc | |
Contact Configuration | SPST | |
Mounting Type | PCB Mount | |
Switching Current | 30A | |
Number of Poles | 1 | |
Series | 45 Series | |
Latching | No | |
Terminal Type | Quick Connect | |
Maximum Switching Voltage AC | 400V | |
Length | 31.4mm | |
Coil Resistance | 1600Ω | |
Coil Power | 360mW | |
Depth | 12.5mm | |
Contact Material | Silver Alloy | |
Minimum Operating Temperature | -40°C | |
Maximum Operating Temperature | +105°C | |
Isolation Coil To Contact | 2.5kV ac | |
Height | 28.5mm | |
Application | General Purpose | |
Select all | ||
---|---|---|
Brand Finder | ||
Coil Voltage 24V dc | ||
Contact Configuration SPST | ||
Mounting Type PCB Mount | ||
Switching Current 30A | ||
Number of Poles 1 | ||
Series 45 Series | ||
Latching No | ||
Terminal Type Quick Connect | ||
Maximum Switching Voltage AC 400V | ||
Length 31.4mm | ||
Coil Resistance 1600Ω | ||
Coil Power 360mW | ||
Depth 12.5mm | ||
Contact Material Silver Alloy | ||
Minimum Operating Temperature -40°C | ||
Maximum Operating Temperature +105°C | ||
Isolation Coil To Contact 2.5kV ac | ||
Height 28.5mm | ||
Application General Purpose | ||
- COO (Country of Origin):
- ES
Finder 45 series Power Relay, 24V DC Coil Voltage, 30A Switching Current - 45.31.7.024.0310
This power relay is a versatile miniature PCB mount relay suitable for various applications. It operates at a coil voltage of 24V DC and is designed for high current switching up to 30A. With a compact size of 31.4mm in length, 12.5mm in depth, and 28.5mm in height, it ensures efficient operation while maintaining a safe isolation distance of 2.5kV AC between the coil and contacts.
Features & Benefits
• Silver alloy contacts offer enhanced conductivity and durability
• Quick connect terminal type enables easy installation
• Maximum switching voltage of 400V AC ensures compatibility with high-voltage systems
• Rated for 30A, suitable for demanding applications
• Wide operating temperature range from -40°C to +105°C
• Compact PCB mount design optimises space utilisation in electronic circuits
• Quick connect terminal type enables easy installation
• Maximum switching voltage of 400V AC ensures compatibility with high-voltage systems
• Rated for 30A, suitable for demanding applications
• Wide operating temperature range from -40°C to +105°C
• Compact PCB mount design optimises space utilisation in electronic circuits
Applications
• Ideal for control and management of electrical power
• Utilised in charging stations and photovoltaic inverters
• Suitable for heating systems, including boilers and furnaces
• Commonly employed in Jacuzzis and hot tubs
• Effective in electronic circuit boards and various automation systems
• Utilised in charging stations and photovoltaic inverters
• Suitable for heating systems, including boilers and furnaces
• Commonly employed in Jacuzzis and hot tubs
• Effective in electronic circuit boards and various automation systems
What is the expected lifespan of this relay under normal operating conditions?
This relay is rated for an electrical life of approximately 30,000 cycles at rated load, making it reliable for extensive use in various applications.
What kind of load can this relay handle without compromising performance?
The relay can switch a maximum load of 4000VA at AC1 for inductive loads, ensuring effective operation without overheating or risk of failure.
How does this relay ensure safety under high-voltage conditions?
With reinforced insulation featuring an 8mm clearance and creepage distance, it provides safe separation between the coil and contact, allowing up to 6kV isolation between them.
What makes this power relay suitable for use in automation systems?
Its quick connect feature facilitates speedy installation, while the durable silver alloy contacts ensure efficient performance in high-current applications.
Is there any specific environmental rating for this relay?
This relay is classified under RT II environmental protection, making it suitable for various controlled settings and capable of withstanding typical industrial conditions.
