TE Connectivity PCB Mount Power Relay, 6V dc Coil, SPST
- RS Stock No.:
- 680-3495
- Mfr. Part No.:
- PCN-106D3MHZ,000
- Brand:
- TE Connectivity
Subtotal (1 unit)*
£3.61
(exc. VAT)
£4.33
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 1 unit(s) ready to ship
- Plus 565 unit(s) shipping from 31 October 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £3.61 |
*price indicative
- RS Stock No.:
- 680-3495
- Mfr. Part No.:
- PCN-106D3MHZ,000
- Brand:
- TE Connectivity
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | TE Connectivity | |
| Coil Voltage | 6V dc | |
| Contact Configuration | SPST | |
| Mounting Type | PCB Mount | |
| Number of Poles | 1 | |
| Latching | No | |
| Series | PCN | |
| Terminal Type | Through Hole | |
| Length | 20mm | |
| Coil Resistance | 300Ω | |
| Depth | 5mm | |
| Maximum Operating Temperature | +70°C | |
| Minimum Operating Temperature | -30°C | |
| Contact Material | Silver Nickel Alloy | |
| Height | 12.5mm | |
| Maximum Switching Power AC | 750VA | |
| Application | PCB | |
Select all | ||
|---|---|---|
Brand TE Connectivity | ||
Coil Voltage 6V dc | ||
Contact Configuration SPST | ||
Mounting Type PCB Mount | ||
Number of Poles 1 | ||
Latching No | ||
Series PCN | ||
Terminal Type Through Hole | ||
Length 20mm | ||
Coil Resistance 300Ω | ||
Depth 5mm | ||
Maximum Operating Temperature +70°C | ||
Minimum Operating Temperature -30°C | ||
Contact Material Silver Nickel Alloy | ||
Height 12.5mm | ||
Maximum Switching Power AC 750VA | ||
Application PCB | ||
- COO (Country of Origin):
- CN
PCN Series - Slim Relays
Extremely slim, only 5mm width
Sensitive coil
Reinforced insulation
Cadmium-free contacts
RT III - washproof
Sensitive coil
Reinforced insulation
Cadmium-free contacts
RT III - washproof
Approvals
UL; VDE
