Finder PCB Mount Power Relay, 120V ac Coil, 8A Switching Current, DPDT
- RS Stock No.:
- 257-7368
- Mfr. Part No.:
- 405281200000
- Brand:
- Finder
Subtotal (1 unit)*
£9.40
(exc. VAT)
£11.28
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 52 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
---|---|
1 + | £9.40 |
*price indicative
- RS Stock No.:
- 257-7368
- Mfr. Part No.:
- 405281200000
- Brand:
- Finder
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | Finder | |
Coil Voltage | 120V ac | |
Contact Configuration | DPDT | |
Mounting Type | PCB Mount | |
Switching Current | 8A | |
Number of Poles | 2 | |
Series | 40 | |
Latching | No | |
Maximum Switching Voltage AC | 400V ac | |
Maximum Switching Voltage DC | 125V dc | |
Maximum Switching Current AC | 15 A | |
Coil Power | 500mW | |
Contact Material | Silver Alloy | |
Life | 100000 Cycles | |
Isolation Coil To Contact | 6kV | |
Maximum Operating Temperature | +85°C | |
Standards Met | cURus, EAC | |
Minimum Operating Temperature | -40°C | |
Number of Coils | Single | |
Select all | ||
---|---|---|
Brand Finder | ||
Coil Voltage 120V ac | ||
Contact Configuration DPDT | ||
Mounting Type PCB Mount | ||
Switching Current 8A | ||
Number of Poles 2 | ||
Series 40 | ||
Latching No | ||
Maximum Switching Voltage AC 400V ac | ||
Maximum Switching Voltage DC 125V dc | ||
Maximum Switching Current AC 15 A | ||
Coil Power 500mW | ||
Contact Material Silver Alloy | ||
Life 100000 Cycles | ||
Isolation Coil To Contact 6kV | ||
Maximum Operating Temperature +85°C | ||
Standards Met cURus, EAC | ||
Minimum Operating Temperature -40°C | ||
Number of Coils Single | ||
RoHS Status: Exempt
- COO (Country of Origin):
- IT
Finder Series 40 Power Relay, 120V AC Coil Voltage, 8A Switching Current - 405281200000
This power relay is a versatile electronic component designed for PCB mount applications, operating at 120V AC. With a robust DPDT configuration and a switching capability of 8A, it excels in managing high voltage situations, featuring a maximum switching voltage of 400V AC and 125V DC. Crafted with AgNi contact material, this relay stands out for its durability, boasting a life cycle of up to 100,000 operations.
Features & Benefits
• Operates at 120V AC with an 8A switching current for reliable performance
• Dual pole, double throw configuration allows for versatile circuit management
• Meets high-voltage standards, supporting up to 400V AC and 125V DC
• Incorporates AgNi contact material for enhanced longevity and conductivity
• Designed for PCB mounting, simplifying installation in electrical assemblies
• Insulation rating of 6kV ensures safety and minimises interference
• Dual pole, double throw configuration allows for versatile circuit management
• Meets high-voltage standards, supporting up to 400V AC and 125V DC
• Incorporates AgNi contact material for enhanced longevity and conductivity
• Designed for PCB mounting, simplifying installation in electrical assemblies
• Insulation rating of 6kV ensures safety and minimises interference
Applications
• Used in medical and dental equipment for precise control
• Suitable for automation in blinds, grilles, and shutters
• Ideal for control panels and electrical distribution setups
• Utilised in electronic circuit boards within vending machines
• Effective in controlling door and gate openers for security systems
• Suitable for automation in blinds, grilles, and shutters
• Ideal for control panels and electrical distribution setups
• Utilised in electronic circuit boards within vending machines
• Effective in controlling door and gate openers for security systems
What is the maximum ambient temperature for operation?
The maximum operating temperature for this relay is +85°C, making it suitable for various environments.
How does the contact configuration benefit circuit designs?
The DPDT configuration enables flexible circuit design options, allowing for the control of two separate circuits with one relay.
What are the implications of using AgNi contact material?
AgNi contact material enhances conductivity and improves durability, significantly extending the relay's operational life.
What specific electrical standards does it meet?
It complies with cURus and EAC standards, ensuring safety and reliability in performance across various applications.
How does this relay handle high voltage applications?
With a maximum switching voltage of 400V AC, it effectively manages high voltage circuits, making it ideal for demanding tasks in industrial settings.
