Finder DIN Rail Non-Latching Relay, 120V ac Coil, 6A Switching Current, DPDT
- RS Stock No.:
- 248-2695
- Mfr. Part No.:
- 7S1481204220
- Brand:
- Finder
Subtotal (1 pack of 5 units)*
£652.60
(exc. VAT)
£783.10
(inc. VAT)
FREE delivery for orders over £60.00
Stocked by manufacturer
- Ready to ship from 04 August 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Pack* |
|---|---|---|
| 5 + | £130.52 | £652.60 |
*price indicative
- RS Stock No.:
- 248-2695
- Mfr. Part No.:
- 7S1481204220
- Brand:
- Finder
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Finder | |
| Coil Voltage | 120V ac | |
| Product Type | Non-Latching Relay | |
| Contact Configuration | DPDT | |
| Mount Type | DIN Rail | |
| Series | 7S | |
| Terminal Type | Quick Connect | |
| Switching Current | 6A | |
| Switching AC Voltage | 250V ac | |
| Minimum Operating Temperature | -40°C | |
| Maximum Operating Temperature | 70°C | |
| Coil Power | 2.3VA | |
| Height | 86.2mm | |
| Standards/Approvals | EAC, CE | |
| Width | 78.8mm | |
| Length | 100.3mm | |
| Contact Material | Silver Tin Oxide | |
| Select all | ||
|---|---|---|
Brand Finder | ||
Coil Voltage 120V ac | ||
Product Type Non-Latching Relay | ||
Contact Configuration DPDT | ||
Mount Type DIN Rail | ||
Series 7S | ||
Terminal Type Quick Connect | ||
Switching Current 6A | ||
Switching AC Voltage 250V ac | ||
Minimum Operating Temperature -40°C | ||
Maximum Operating Temperature 70°C | ||
Coil Power 2.3VA | ||
Height 86.2mm | ||
Standards/Approvals EAC, CE | ||
Width 78.8mm | ||
Length 100.3mm | ||
Contact Material Silver Tin Oxide | ||
The Finders 7S series of Modular relay with forcibly guided contacts have 22.5 mm wide, screwless terminals, and 4 contacts. This relay works on 120 Vac (50/60 Hz).
It has 2 NO & 2 NC (DPST-NO + DPST-NC) contacts
The contact material is AgSnO2
