Finder DIN Rail Non-Latching Relay, 48V dc Coil, 6A Switching Current, DPDT
- RS Stock No.:
- 247-9238
- Mfr. Part No.:
- 7S1490480220
- Brand:
- Finder
Subtotal (1 pack of 5 units)*
£477.18
(exc. VAT)
£572.615
(inc. VAT)
FREE delivery for orders over £60.00
Stocked by manufacturer
- Ready to ship from 04 August 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Pack* |
|---|---|---|
| 5 + | £95.436 | £477.18 |
*price indicative
- RS Stock No.:
- 247-9238
- Mfr. Part No.:
- 7S1490480220
- Brand:
- Finder
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Finder | |
| Product Type | Non-Latching Relay | |
| Coil Voltage | 48V dc | |
| Contact Configuration | DPDT | |
| Mount Type | DIN Rail | |
| Terminal Type | Screw | |
| Switching Current | 6A | |
| Switching DC Voltage | 60V dc | |
| Minimum Operating Temperature | -40°C | |
| Switching AC Voltage | 240V ac | |
| Maximum Operating Temperature | 70°C | |
| Height | 15mm | |
| Standards/Approvals | RoHS | |
| Coil Power | 1W | |
| Length | 50mm | |
| Width | 10mm | |
| Contact Material | Silver Alloy | |
| Contact Resistance | 100mΩ | |
| Select all | ||
|---|---|---|
Brand Finder | ||
Product Type Non-Latching Relay | ||
Coil Voltage 48V dc | ||
Contact Configuration DPDT | ||
Mount Type DIN Rail | ||
Terminal Type Screw | ||
Switching Current 6A | ||
Switching DC Voltage 60V dc | ||
Minimum Operating Temperature -40°C | ||
Switching AC Voltage 240V ac | ||
Maximum Operating Temperature 70°C | ||
Height 15mm | ||
Standards/Approvals RoHS | ||
Coil Power 1W | ||
Length 50mm | ||
Width 10mm | ||
Contact Material Silver Alloy | ||
Contact Resistance 100mΩ | ||
The Finders 7S series of Modular relay with forcibly guided contacts have 22.5 mm wide, screwless terminals, and 4 contacts. This relay works on 48 Vdc.
It has 2 NO & 2 NC (DPST-NO + DPST-NC) contacts
