Lovato DIN Rail Non-Latching Relay, 110V dc Coil, 10A Switching Current, 3PDT
- RS Stock No.:
- 247-9606
- Mfr. Part No.:
- HR703CD110
- Brand:
- Lovato
Subtotal (1 unit)*
£11.48
(exc. VAT)
£13.78
(inc. VAT)
Stock information currently inaccessible - Please check back later
Units | Per unit |
|---|---|
| 1 + | £11.48 |
*price indicative
- RS Stock No.:
- 247-9606
- Mfr. Part No.:
- HR703CD110
- Brand:
- Lovato
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Lovato | |
| Product Type | Non-Latching Relay | |
| Coil Voltage | 110V dc | |
| Contact Configuration | 3PDT | |
| Mount Type | DIN Rail | |
| Series | HR703C | |
| Terminal Type | Screw | |
| Switching Current | 10A | |
| Switching Power | 500VA | |
| Minimum Operating Temperature | -40°C | |
| Switching DC Voltage | 110V dc | |
| Switching AC Voltage | 230V ac | |
| Maximum Operating Temperature | 55°C | |
| Height | 65.5mm | |
| Standards/Approvals | IEC/EN 61810 | |
| Coil Power | 1.5W | |
| Contact Material | Silver Nickel Alloy | |
| Contact Resistance | 100mΩ | |
| Select all | ||
|---|---|---|
Brand Lovato | ||
Product Type Non-Latching Relay | ||
Coil Voltage 110V dc | ||
Contact Configuration 3PDT | ||
Mount Type DIN Rail | ||
Series HR703C | ||
Terminal Type Screw | ||
Switching Current 10A | ||
Switching Power 500VA | ||
Minimum Operating Temperature -40°C | ||
Switching DC Voltage 110V dc | ||
Switching AC Voltage 230V ac | ||
Maximum Operating Temperature 55°C | ||
Height 65.5mm | ||
Standards/Approvals IEC/EN 61810 | ||
Coil Power 1.5W | ||
Contact Material Silver Nickel Alloy | ||
Contact Resistance 100mΩ | ||
The Lovato is a 11-PIN Industrial relay with LED state indicator and mechanical actuator and has control voltage of 110VDC, rated current of 10A with 3 C/O contact configuration.
Maximum cycle frequency cycles/h 3600
Ambient operating temperature from -40 to +55 °C
