Lovato Non-Latching Relay, 12V dc Coil, 5A Switching Current, 4PDT
- RS Stock No.:
- 247-9586
- Mfr. Part No.:
- HR604CD012
- Brand:
- Lovato
Subtotal (1 unit)*
£7.06
(exc. VAT)
£8.47
(inc. VAT)
FREE delivery for orders over £60.00
In Stock
- 23 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £7.06 |
*price indicative
- RS Stock No.:
- 247-9586
- Mfr. Part No.:
- HR604CD012
- Brand:
- Lovato
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Lovato | |
| Coil Voltage | 12V dc | |
| Product Type | Non-Latching Relay | |
| Contact Configuration | 4PDT | |
| Series | HR604C | |
| Terminal Type | Socket | |
| Switching Current | 5A | |
| Switching DC Voltage | 100V dc | |
| Switching AC Voltage | 500V ac | |
| Minimum Operating Temperature | -40°C | |
| Maximum Operating Temperature | 70°C | |
| Coil Power | 1.1W | |
| Height | 75.2mm | |
| Length | 81mm | |
| Width | 27.2mm | |
| Standards/Approvals | Compliance IEC/EN 61810 | |
| Contact Material | Silver Nickel Alloy | |
| Contact Resistance | 100mΩ | |
| Select all | ||
|---|---|---|
Brand Lovato | ||
Coil Voltage 12V dc | ||
Product Type Non-Latching Relay | ||
Contact Configuration 4PDT | ||
Series HR604C | ||
Terminal Type Socket | ||
Switching Current 5A | ||
Switching DC Voltage 100V dc | ||
Switching AC Voltage 500V ac | ||
Minimum Operating Temperature -40°C | ||
Maximum Operating Temperature 70°C | ||
Coil Power 1.1W | ||
Height 75.2mm | ||
Length 81mm | ||
Width 27.2mm | ||
Standards/Approvals Compliance IEC/EN 61810 | ||
Contact Material Silver Nickel Alloy | ||
Contact Resistance 100mΩ | ||
- COO (Country of Origin):
- CN
The Lovato is a Industrial relay with LED state indicator and mechanical actuator has control voltage of 12VDC, rated current of 5A with contact configuration 4 C/O contact.
Maximum cycle frequency cycles/h 3600
Ambient operating temperature from -40 to +55 °C
