Finder DIN Rail Non-Latching Relay, 230V ac Coil, 6A Switching Current, 3PDT
- RS Stock No.:
- 247-9254
- Distrelec Article No.:
- 304-32-891
- Mfr. Part No.:
- 7S3482304310
- Brand:
- Finder
Subtotal (1 pack of 5 units)*
£538.18
(exc. VAT)
£645.815
(inc. VAT)
Stock information currently inaccessible - Please check back later
Units | Per unit | Per Pack* |
|---|---|---|
| 5 + | £107.636 | £538.18 |
*price indicative
- RS Stock No.:
- 247-9254
- Distrelec Article No.:
- 304-32-891
- Mfr. Part No.:
- 7S3482304310
- Brand:
- Finder
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Finder | |
| Product Type | Non-Latching Relay | |
| Coil Voltage | 230V ac | |
| Contact Configuration | 3PDT | |
| Mount Type | DIN Rail | |
| Terminal Type | Screw | |
| Switching Current | 6A | |
| Minimum Operating Temperature | -40°C | |
| Switching DC Voltage | 60V dc | |
| Switching AC Voltage | 240V ac | |
| Maximum Operating Temperature | 70°C | |
| Width | 10mm | |
| Standards/Approvals | RoHS | |
| Height | 15mm | |
| Length | 50mm | |
| Coil Power | 1W | |
| Contact Material | Silver Alloy | |
| Contact Resistance | 100mΩ | |
| Select all | ||
|---|---|---|
Brand Finder | ||
Product Type Non-Latching Relay | ||
Coil Voltage 230V ac | ||
Contact Configuration 3PDT | ||
Mount Type DIN Rail | ||
Terminal Type Screw | ||
Switching Current 6A | ||
Minimum Operating Temperature -40°C | ||
Switching DC Voltage 60V dc | ||
Switching AC Voltage 240V ac | ||
Maximum Operating Temperature 70°C | ||
Width 10mm | ||
Standards/Approvals RoHS | ||
Height 15mm | ||
Length 50mm | ||
Coil Power 1W | ||
Contact Material Silver Alloy | ||
Contact Resistance 100mΩ | ||
The Finder's 7S series modular relays with forcibly guided contacts for safety applications such as used in railways, elevators and lifts, hoists and cranes, carousel warehouses, escalators, elevators and lifts, automatic car-washes, chemical and petrolchemical, process industry.
4 pole 6 A 3 NO + 1 NC (3PST-NO + SPST-NC)
Functional reliability in machinery and plant engineering
DC and AC supply versions
Coil status visual indication with LED
35 mm rail (EN 60715) mount
22.5 mm wide, screw terminals
