Omron PCB Power Relay, 110V ac Coil, 10A Switching Current, SPDT
- RS Stock No.:
- 213-2091
- Mfr. Part No.:
- G2R-1 AC100/(110)
- Brand:
- Omron
Bulk discount available
Subtotal (1 unit)*
£7.97
(exc. VAT)
£9.56
(inc. VAT)
FREE delivery for orders over £60.00
In Stock
- Plus 107 unit(s) shipping from 27 April 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 - 9 | £7.97 |
| 10 - 24 | £6.82 |
| 25 - 49 | £5.98 |
| 50 + | £5.32 |
*price indicative
- RS Stock No.:
- 213-2091
- Mfr. Part No.:
- G2R-1 AC100/(110)
- Brand:
- Omron
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Omron | |
| Coil Voltage | 110V ac | |
| Product Type | Power Relay | |
| Contact Configuration | SPDT | |
| Mount Type | PCB | |
| Series | G2R-1 | |
| Terminal Type | PCB Pin | |
| Switching Current | 10A | |
| Switching AC Voltage | 380V ac | |
| Switching DC Voltage | 125V dc | |
| Minimum Operating Temperature | -40°C | |
| Coil Resistance | 4.6kΩ | |
| Maximum Operating Temperature | 70°C | |
| Standards/Approvals | RoHS | |
| Width | 13mm | |
| Height | 29.5mm | |
| Coil Power | 300mW | |
| Length | 29mm | |
| Contact Material | Silver Alloy | |
| Contact Resistance | 30mΩ | |
| Select all | ||
|---|---|---|
Brand Omron | ||
Coil Voltage 110V ac | ||
Product Type Power Relay | ||
Contact Configuration SPDT | ||
Mount Type PCB | ||
Series G2R-1 | ||
Terminal Type PCB Pin | ||
Switching Current 10A | ||
Switching AC Voltage 380V ac | ||
Switching DC Voltage 125V dc | ||
Minimum Operating Temperature -40°C | ||
Coil Resistance 4.6kΩ | ||
Maximum Operating Temperature 70°C | ||
Standards/Approvals RoHS | ||
Width 13mm | ||
Height 29.5mm | ||
Coil Power 300mW | ||
Length 29mm | ||
Contact Material Silver Alloy | ||
Contact Resistance 30mΩ | ||
- COO (Country of Origin):
- ID
The Omron G2R PCB power relay has single -pole with 10A Switching Capability. The G2R PCB power relay has PCB terminals shape with Single NO/NC contacts type.
Flux protection
Single-side stable model
Standard Classification
