Hongfa Europe GMBH PCB Mount Power Relay, 24V dc Coil, 10A Switching Current, DPST

View all Power Relays
Unavailable
RS will no longer stock this product.
RS Stock No.:
176-2860
Mfr. Part No.:
HF140FF/024-2HTF
Brand:
Hongfa Europe GMBH
Find similar products by selecting one or more attributes.
Select all

Brand

Hongfa Europe GMBH

Coil Voltage

24V dc

Contact Configuration

DPST

Mounting Type

PCB Mount

Switching Current

10A

Number of Poles

2

Latching

No

Terminal Type

PCB Pin

Maximum Switching Voltage AC

250V

Maximum Switching Voltage DC

30V dc

Maximum Switching Current AC

10 A

Maximum Switching Current DC

10 A

Length

29mm

Coil Resistance

1100Ω

Coil Power

530mW

Contact Material

Silver Alloy

Depth

13mm

Series

HF140FF

Height

26.3mm

Life

1 x 10^7 cycles

Maximum Operating Temperature

+85°C

Minimum Operating Temperature

-40°C

Isolation Coil To Contact

5kV

Maximum Switching Power AC

2.5 kVA

Maximum Switching Power DC

240 W

COO (Country of Origin):
CN

Hongfa DPNO Non-Latching Relay


The Hongfa DPNO non-latching electromagnetic 2-pole PCB mount relay is a miniature form power relay of intermediate category. It is actuated with the help of a 24VDC and up to 10A DC/AC coil. This relay has silver alloy contacts. The contact arrangement is of 2 Form A type and insulation standard is Class F.

Features and Benefits


• High power switching up to 240W in case of DC
• Service temperature range between -40°C and 85°C
• Isolation voltage between coil and contact is 5KVAC
• Sensitive coil power
• Flux proofed type
• Sockets available
• Environmental friendly product

Applications


• Used as a control device
• Automotive industry
