Hongfa Europe GMBH PCB Mount Power Relay, 12V dc Coil, 20A Switching Current, SPDT

View all Power Relays

Subtotal (1 tray of 50 units)*

£136.00

(exc. VAT)

£163.00

(inc. VAT)

Add to Basket
Select or type quantity
In Stock
  • 200 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units
Per unit
Per Tray*
50 +£2.72£136.00

*price indicative

RS Stock No.:
176-2782
Mfr. Part No.:
HF14FW/012-ZSPTF
Brand:
Hongfa Europe GMBH
Find similar products by selecting one or more attributes.
Select all

Brand

Hongfa Europe GMBH

Coil Voltage

12V dc

Contact Configuration

SPDT

Mounting Type

PCB Mount

Switching Current

20A

Number of Poles

1

Latching

No

Terminal Type

PCB Pin

Maximum Switching Voltage AC

277V

Maximum Switching Voltage DC

30V dc

Maximum Switching Current AC

20 A

Maximum Switching Current DC

20 A

Length

29mm

Coil Resistance

275Ω

Coil Power

720mW

Series

HF14FW

Life

1 x 10^7 cycles

Isolation Coil To Contact

4kV

Maximum Operating Temperature

+85°C

Height

26.5mm

Minimum Operating Temperature

-40°C

Contact Material

Silver Alloy

Depth

13mm

Maximum Switching Power DC

480 W

Maximum Switching Power AC

5.54 kVA

COO (Country of Origin):
CN
20A switching capability
4kV dielectric strength (between coil and contacts)

1 Form A, 1 Form B and 1 Form C configurations
Sockets available
Plastic sealed and dust protected types available

Environmental friendly product
Outline Dimensions: (29.0 x 13.0 x 26.5) mm
