Phoenix Contact PCB Mount Power Relay, 24V dc Coil, 10mA Switching Current, SPDT
- RS Stock No.:
- 134-8697
- Distrelec Article No.:
- 303-96-918
- Mfr. Part No.:
- 2909642
- Brand:
- Phoenix Contact
Subtotal (1 unit)*
£17.11
(exc. VAT)
£20.53
(inc. VAT)
FREE delivery for orders over £50.00
- 51 unit(s) ready to ship
- Plus 50 unit(s) ready to ship from another location
Units | Per unit |
---|---|
1 - 9 | £17.11 |
10 - 49 | £16.92 |
50 - 99 | £16.19 |
100 + | £15.40 |
*price indicative
- RS Stock No.:
- 134-8697
- Distrelec Article No.:
- 303-96-918
- Mfr. Part No.:
- 2909642
- Brand:
- Phoenix Contact
Select all | Attribute | Value |
---|---|---|
Brand | Phoenix Contact | |
Coil Voltage | 24V dc | |
Contact Configuration | SPDT | |
Mounting Type | PCB Mount | |
Switching Current | 10mA | |
Number of Poles | 1 | |
Latching | No | |
Series | REL-MR- 24DC/21/MS | |
Terminal Type | PCB Pin | |
Maximum Switching Voltage AC | 250V | |
Maximum Switching Voltage DC | 250V dc | |
Maximum Switching Current AC | 3 A | |
Maximum Switching Current DC | 2 A | |
Length | 16mm | |
Coil Resistance | 3.39 kO | |
Height | 28mm | |
Minimum Operating Temperature | -40°C | |
Maximum Operating Temperature | +85°C | |
Depth | 5mm | |
Contact Material | Silver Alloy | |
Standards Met | EAC | |
Width | 5mm | |
Maximum Switching Power AC | 1.5 kVA | |
Application | Relay | |
Dimensions | 28 x 5 x16mm | |
Select all | ||
---|---|---|
Brand Phoenix Contact | ||
Coil Voltage 24V dc | ||
Contact Configuration SPDT | ||
Mounting Type PCB Mount | ||
Switching Current 10mA | ||
Number of Poles 1 | ||
Latching No | ||
Series REL-MR- 24DC/21/MS | ||
Terminal Type PCB Pin | ||
Maximum Switching Voltage AC 250V | ||
Maximum Switching Voltage DC 250V dc | ||
Maximum Switching Current AC 3 A | ||
Maximum Switching Current DC 2 A | ||
Length 16mm | ||
Coil Resistance 3.39 kO | ||
Height 28mm | ||
Minimum Operating Temperature -40°C | ||
Maximum Operating Temperature +85°C | ||
Depth 5mm | ||
Contact Material Silver Alloy | ||
Standards Met EAC | ||
Width 5mm | ||
Maximum Switching Power AC 1.5 kVA | ||
Application Relay | ||
Dimensions 28 x 5 x16mm | ||
- COO (Country of Origin):
- CZ
REL-MR Plug In Power Relay
Features and Benefits
Coil voltages 12 to 60 V dc
Yellow LED indicator
Phoenix Contact Power Relay, PCB Mounting, 24V DC Voltage Rating - REL-MR- 24DC/21/MS - 2909642
For easy installation, the relay mounts onto your printed circuit board (PCB) securely with five built-in pins. Its slim dimensions of 28 (H) x 5 (W) x 16mm (D) mean multiple units can be arranged side-by-side, and there's no need for spacing. At a light 4.7g, it won't add unnecessary weight to your setup. This unit has a maximum switching voltage of 250V DC/AC, so it's useful for low-voltage applications including audiovisual equipment, medical appliances and communication devices.
Features & Benefits
• Wide operating temperature range of -40°C to +85°C means it's unfazed by harsh industrial conditions
