Relpol PCB Power Relay, 110V dc Coil, 16A Switching Current, 1 CO
- RS Stock No.:
- 134-8382
- Mfr. Part No.:
- RM85-2011-35-1110
- Brand:
- Relpol
Subtotal (1 unit)*
£10.66
(exc. VAT)
£12.79
(inc. VAT)
FREE delivery for orders over £60.00
In Stock
- Plus 18 unit(s) shipping from 04 May 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £10.66 |
*price indicative
- RS Stock No.:
- 134-8382
- Mfr. Part No.:
- RM85-2011-35-1110
- Brand:
- Relpol
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Relpol | |
| Coil Voltage | 110V dc | |
| Product Type | Power Relay | |
| Contact Configuration | 1 CO | |
| Mount Type | PCB | |
| Series | RM85 | |
| Terminal Type | PCB Pin | |
| Switching Current | 16A | |
| Switching AC Voltage | 24V ac | |
| Minimum Operating Temperature | -40°C | |
| Switching Power | 4kVA | |
| Switching DC Voltage | 24V dc | |
| Coil Resistance | 25.2kΩ | |
| Maximum Operating Temperature | 85°C | |
| Standards/Approvals | EAC, RoHS | |
| Width | 12.7mm | |
| Coil Power | 480mW | |
| Length | 29mm | |
| Height | 15.7mm | |
| Contact Material | Silver Alloy | |
| Contact Resistance | 100mΩ | |
| Select all | ||
|---|---|---|
Brand Relpol | ||
Coil Voltage 110V dc | ||
Product Type Power Relay | ||
Contact Configuration 1 CO | ||
Mount Type PCB | ||
Series RM85 | ||
Terminal Type PCB Pin | ||
Switching Current 16A | ||
Switching AC Voltage 24V ac | ||
Minimum Operating Temperature -40°C | ||
Switching Power 4kVA | ||
Switching DC Voltage 24V dc | ||
Coil Resistance 25.2kΩ | ||
Maximum Operating Temperature 85°C | ||
Standards/Approvals EAC, RoHS | ||
Width 12.7mm | ||
Coil Power 480mW | ||
Length 29mm | ||
Height 15.7mm | ||
Contact Material Silver Alloy | ||
Contact Resistance 100mΩ | ||
Relpol RM85 Series Miniature Relays
Relpol RM85 series miniature industrial relays for general purpose applications. All relays are designed for PCB mounting or in plug-in sockets.
Miniature dimensions
Cadmium-free contacts
AC and DC coils
RoHS compliant
