Relpol PCB Mount Power Relay, 110V dc Coil, 8A Switching Current, DPDT
- RS Stock No.:
- 134-8379
- Mfr. Part No.:
- RM84-2012-35-1110
- Brand:
- Relpol
Subtotal (1 unit)**
£8.24
(exc. VAT)
£9.89
(inc. VAT)
162 In stock - FREE next working day delivery available*
* Delivery dates may change based on your chosen quantity and delivery address.
FREE delivery for orders over £50.00
Check stock levels
Units | Per unit |
|---|---|
| 1 + | £8.24 |
**price indicative
- RS Stock No.:
- 134-8379
- Mfr. Part No.:
- RM84-2012-35-1110
- Brand:
- Relpol
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Relpol | |
| Coil Voltage | 110V dc | |
| Contact Configuration | DPDT | |
| Mounting Type | PCB Mount | |
| Switching Current | 8A | |
| Number of Poles | 2 | |
| Latching | No | |
| Terminal Type | PCB Pin | |
| Maximum Switching Voltage AC | 440V | |
| Maximum Switching Voltage DC | 24V dc | |
| Length | 29mm | |
| Coil Resistance | 25200Ω | |
| Coil Power | 400 → 480mW | |
| Maximum Operating Temperature | +85°C | |
| Isolation Coil To Contact | 5kV ac | |
| Height | 15.7mm | |
| Minimum Operating Temperature | -40°C | |
| Life | >100000 (Electrical) cycles, >30000000 (Mechanical) cycles | |
| Depth | 12.7mm | |
| Contact Material | Silver Alloy | |
| Standards Met | CCC, CSA, CULus, EAC, VDE | |
| Maximum Switching Power AC | 2 kVA | |
Select all | ||
|---|---|---|
Brand Relpol | ||
Coil Voltage 110V dc | ||
Contact Configuration DPDT | ||
Mounting Type PCB Mount | ||
Switching Current 8A | ||
Number of Poles 2 | ||
Latching No | ||
Terminal Type PCB Pin | ||
Maximum Switching Voltage AC 440V | ||
Maximum Switching Voltage DC 24V dc | ||
Length 29mm | ||
Coil Resistance 25200Ω | ||
Coil Power 400 → 480mW | ||
Maximum Operating Temperature +85°C | ||
Isolation Coil To Contact 5kV ac | ||
Height 15.7mm | ||
Minimum Operating Temperature -40°C | ||
Life >100000 (Electrical) cycles, >30000000 (Mechanical) cycles | ||
Depth 12.7mm | ||
Contact Material Silver Alloy | ||
Standards Met CCC, CSA, CULus, EAC, VDE | ||
Maximum Switching Power AC 2 kVA | ||
