RS PRO PCB Mount Power Relay, 24V dc Coil, 25A Switching Current, SPST
- RS Stock No.:
- 476-551
- Brand:
- RS PRO
Bulk discount available
Subtotal (1 unit)*
£5.01
(exc. VAT)
£6.01
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 111 unit(s) ready to ship
- Plus 5 unit(s) shipping from 29 October 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 - 24 | £5.01 |
| 25 - 49 | £4.52 |
| 50 - 99 | £4.08 |
| 100 - 249 | £3.61 |
| 250 + | £3.20 |
*price indicative
- RS Stock No.:
- 476-551
- Brand:
- RS PRO
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | RS PRO | |
| Coil Voltage | 24V dc | |
| Contact Configuration | SPST | |
| Mounting Type | PCB Mount | |
| Switching Current | 25A | |
| Number of Poles | 1 | |
| Latching | No | |
| Terminal Type | Through Hole | |
| Maximum Switching Voltage AC | 250V ac | |
| Length | 30.5mm | |
| Coil Resistance | 640Ω | |
| Coil Power | 900mW | |
| Height | 33.5mm | |
| Life | 100000 (Electrical) cycles, 2000000 (Mechanical) cycles | |
| Isolation Coil To Contact | 4.5kV ac | |
| Contact Material | Silver Alloy | |
| Standards Met | CQC, CULus, RoHS Compliant | |
| Minimum Operating Temperature | -25°C | |
| Maximum Operating Temperature | +85°C | |
| Depth | 16mm | |
| Maximum Switching Power AC | 6.25 kVA | |
| Application | Power | |
Select all | ||
|---|---|---|
Brand RS PRO | ||
Coil Voltage 24V dc | ||
Contact Configuration SPST | ||
Mounting Type PCB Mount | ||
Switching Current 25A | ||
Number of Poles 1 | ||
Latching No | ||
Terminal Type Through Hole | ||
Maximum Switching Voltage AC 250V ac | ||
Length 30.5mm | ||
Coil Resistance 640Ω | ||
Coil Power 900mW | ||
Height 33.5mm | ||
Life 100000 (Electrical) cycles, 2000000 (Mechanical) cycles | ||
Isolation Coil To Contact 4.5kV ac | ||
Contact Material Silver Alloy | ||
Standards Met CQC, CULus, RoHS Compliant | ||
Minimum Operating Temperature -25°C | ||
Maximum Operating Temperature +85°C | ||
Depth 16mm | ||
Maximum Switching Power AC 6.25 kVA | ||
Application Power | ||
- COO (Country of Origin):
- CN
High Power Relays
Heavy load up to 5000VA, ideal for motor switching
Withstands inrush current of 80A
Fitted with 6.3mm quick connect male terminals
4.5kV dielectric strength (between coil and contacts)
Flux proof construction
Withstands inrush current of 80A
Fitted with 6.3mm quick connect male terminals
4.5kV dielectric strength (between coil and contacts)
Flux proof construction
Approvals
UL (File no. E134517), CQC (File no. CQC02001001955), VDE
