Schaffner, FN406 1A 250 V ac DC → 400Hz, Through Hole RFI Filter, PC Pin, Single Phase
- RS Stock No.:
- 883-8027
- Mfr. Part No.:
- FN406B-1-02
- Brand:
- Schaffner
Currently unavailable
We don’t know if this item will be back in stock, it is being discontinued by the manufacturer.
- RS Stock No.:
- 883-8027
- Mfr. Part No.:
- FN406B-1-02
- Brand:
- Schaffner
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Schaffner | |
| Maximum Current Rating | 1A | |
| Maximum Voltage Rating | 250 V ac | |
| Mounting Type | Through Hole | |
| Termination Style | PC Pin | |
| Number of Phases | 1 | |
| Number of Stages | Single Stage | |
| Series | FN406 | |
| Operating Frequency | DC → 400Hz | |
| Length | 45mm | |
| Depth | 15mm | |
| Height | 29.5mm | |
| Capacitance | 100nF | |
| Inductance | 12 mH | |
| Dimensions | 45 x 15 x 29.5mm | |
| Minimum Operating Temperature | -25°C | |
| Leakage Current | 0.002 mA | |
| Maximum Operating Temperature | +100°C | |
| Resistance | 1MΩ | |
| Standards Met | UL 94 V-0 | |
