Schaffner, FN 343 6A 250 V ac 400Hz, Chassis Mount RFI Filter, Tab

  • RS Stock No. 170-4944
  • Mfr. Part No. FN 343-6/05
  • Brand Schaffner
Technical Reference
Legislation and Compliance
RoHS Certificate of Compliance
Product Details

FN 343 Series Two-stage General Purpose Filters

Schaffner performance FN 343 EMI Filters are compact in design for easy and fast chassis mounting. Single-phase filters provide an excellent
Attenuation performance, based on chokes with high saturation and excellent thermal behaviour. Also feature integrated earth line choke. Rated currents from 1 A to 10 A

Applications

Electrical and electronic equipment
Household equipment
Power supplies
Consumer goods
Office automation equipment
Datacom equipment

Specifications
Attribute Value
Maximum Current Rating 6A
Maximum Voltage Rating 250 V ac
Mounting Type Chassis Mount
Termination Style Tab
Series FN 343
Number of Stages Two Stage
Operating Frequency 400Hz
Length 70mm
Height 30.3mm
Capacitance 2.2 nF, 100 nF
Inductance 400 μH, 430 μH, 770 μH
Minimum Operating Temperature -25°C
Leakage Current 0.34 mA
Maximum Operating Temperature +100°C
Resistance 1MΩ
Available to back order for despatch 15/06/2020
Price Each (In a Box of 112)
£ 30.689
(exc. VAT)
£ 36.827
(inc. VAT)
Units
Per unit
Per Box*
112 +
£30.689
£3,437.168
*price indicative
