Vishay Power Factor Correction Capacitor 154 μF 28.1 kvar 33.72 kvar 3
- RS Stock No.:
- 187-5385
- Distrelec Article No.:
- 302-13-274
- Mfr. Part No.:
- PhMKP440.3.28,10-S84
- Brand:
- Vishay
Bulk discount available
View bulk pricing optionsSubtotal (1 unit)*
£173.59
(exc. VAT)
£208.31
(inc. VAT)
FREE delivery for orders over £60.00
Temporarily out of stock
- 1 unit(s) shipping from 27 July 2026
- Plus 40 unit(s) shipping from 06 August 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 - 1 | £173.59 |
| 2 - 4 | £156.23 |
| 5 + | £147.55 |
*price indicative
- RS Stock No.:
- 187-5385
- Distrelec Article No.:
- 302-13-274
- Mfr. Part No.:
- PhMKP440.3.28,10-S84
- Brand:
- Vishay
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Vishay | |
| Product Type | Power Factor Correction Capacitor | |
| Rated AC Voltage | 440V ac | |
| Dielectric | Polypropylene | |
| Pin Count | 3 | |
| Standards/Approvals | ESTA LVAC, IEC/EN 60831-1 + 2 (VDE 0560‑46+47), UL/ULC, CE | |
| Weight | 1.7kg | |
| Mount Type | Stud Mount | |
| Maximum Operating Temperature | 55°C | |
| Width | 88.2mm | |
| Series | PHMKP, oil-filled | |
| Number of Phases | 3 | |
| Minimum Operating Temperature | -40°C | |
| Height | 265mm | |
| Length | 265mm | |
| kVAr 50Hz | 28.1kvar | |
| Tolerance | ±5 % | |
| Capacitance | 154μF | |
| kVAr 60Hz | 33.72kvar | |
| Terminal Type | Screw | |
| Select all | ||
|---|---|---|
Brand Vishay | ||
Product Type Power Factor Correction Capacitor | ||
Rated AC Voltage 440V ac | ||
Dielectric Polypropylene | ||
Pin Count 3 | ||
Standards/Approvals ESTA LVAC, IEC/EN 60831-1 + 2 (VDE 0560‑46+47), UL/ULC, CE | ||
Weight 1.7kg | ||
Mount Type Stud Mount | ||
Maximum Operating Temperature 55°C | ||
Width 88.2mm | ||
Series PHMKP, oil-filled | ||
Number of Phases 3 | ||
Minimum Operating Temperature -40°C | ||
Height 265mm | ||
Length 265mm | ||
kVAr 50Hz 28.1kvar | ||
Tolerance ±5 % | ||
Capacitance 154μF | ||
kVAr 60Hz 33.72kvar | ||
Terminal Type Screw | ||
RoHS Status: Exempt
LVAC Power Capacitors Terminal Block With Spring Connection
Maintenance free
Reduced assembly times up to 60 %
Vibration proof in wind power plants and during transport
APPLICATIONS
Wind power plants
Solar panels and inverters
Thermal power station
