RS PRO Fire Performance 1.5 mm² 5 Core Power Cable, H05Z1Z1-F, White, 100m
- RS Stock No.:
- 836-0760
- Brand:
- RS PRO
Subtotal (1 reel of 100 metres)*
£322.77
(exc. VAT)
£387.32
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 26 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Reel(s) | Per Reel | Per Metre* |
---|---|---|
1 + | £322.77 | £3.228 |
*price indicative
- RS Stock No.:
- 836-0760
- Brand:
- RS PRO
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | RS PRO | |
Cross Sectional Area | 1.5 mm² | |
Number of Cores | 5 | |
Sheath Colour | White | |
Length | 100m | |
Cable Type | Fire Performance | |
Outer Diameter | 9.3 → 11.6mm | |
CPR Certification | Eca | |
Voltage Rating | 500 V | |
European Harmonised Code | H05Z1Z1-F | |
Number of Strands | 27 | |
American Wire Gauge | 15 AWG | |
Conductor Resistance | 13.3 Ω/km | |
Conductor Material | Copper | |
Maximum Operating Temperature | +70°C | |
Size of Strands | 0.25 mm | |
Insulation Material | Thermoplastic | |
Standards Met | BS EN 50525 | |
Fire Behaviour | Flame Retardant | |
Minimum Operating Temperature | -5°C | |
Select all | ||
---|---|---|
Brand RS PRO | ||
Cross Sectional Area 1.5 mm² | ||
Number of Cores 5 | ||
Sheath Colour White | ||
Length 100m | ||
Cable Type Fire Performance | ||
Outer Diameter 9.3 → 11.6mm | ||
CPR Certification Eca | ||
Voltage Rating 500 V | ||
European Harmonised Code H05Z1Z1-F | ||
Number of Strands 27 | ||
American Wire Gauge 15 AWG | ||
Conductor Resistance 13.3 Ω/km | ||
Conductor Material Copper | ||
Maximum Operating Temperature +70°C | ||
Size of Strands 0.25 mm | ||
Insulation Material Thermoplastic | ||
Standards Met BS EN 50525 | ||
Fire Behaviour Flame Retardant | ||
Minimum Operating Temperature -5°C | ||
- COO (Country of Origin):
- TR
RS PRO 5-Core 1.5 mm² H05Z1Z1-F Power Cable, White, 100 m, 500 V
This five-core power cable from RS PRO is an ideal choice for more complex indoor wiring tasks that require earthing. It comes in a reel that extends up to 100 metres, so you can extend the distance between the power source and your appliance as needed.
It has an LSZH (low smoke zero halogen) classification, which means that it won't release toxic halogen fumes in the case of a fire. This is an essential safety feature for cabling in public places. It's also encased in a flame-retardant, insulated thermoplastic sheath that's extremely robust. Cables of this type are suitable for use in a wide range of high-traffic, enclosed areas, including airports, train stations and hospitals.
It has an LSZH (low smoke zero halogen) classification, which means that it won't release toxic halogen fumes in the case of a fire. This is an essential safety feature for cabling in public places. It's also encased in a flame-retardant, insulated thermoplastic sheath that's extremely robust. Cables of this type are suitable for use in a wide range of high-traffic, enclosed areas, including airports, train stations and hospitals.
Features and Benefits
- Wire size of 15 AWG (American Wire Gauge)
- Low smoke zero halogen (LSZH) cable type
- Copper conductor material
- Conductor resistance of 13.3 Ω/km
- Cross-sectional area of 1.5 mm²
- Flame-retardant
- H05Z1Z1-F harmonised code, indicating superior fire safety
- Thermoplastic insulation material
- Length of 100 m
- Operating temperature range of -5°C to +70°C
- Five cores
- 27 strands
- Outer diameter of 9.3 to 11.6 mm
- Reference of 3185B
- Indoor series
- White sheath colour
- Strand size of 0.25 mm
- Meets BS EN 50525 standards for power cables for domestic and industrial appliances
- Voltage rating of 500 V
