Vishay 100Ω Rotary Potentiometer 10-Turns 1-Gang Panel Mount, 534B1101JL
- RS Stock No.:
- 167-9485
- Mfr. Part No.:
- 534B1101JL
- Brand:
- Vishay
490 In stock - FREE next working day delivery available
Added
Price Each (In a Box of 10)
£27.352
(exc. VAT)
£32.822
(inc. VAT)
| Units | Per unit | Per Box* |
| 10 - 10 | £27.352 | £273.52 |
| 20 + | £17.779 | £177.79 |
| *price indicative | ||
- RS Stock No.:
- 167-9485
- Mfr. Part No.:
- 534B1101JL
- Brand:
- Vishay
Legislation and Compliance
Product Details
534 Series Rotary Potentiometers
Vishay’s range of high quality rotary potentiometers bring you the best build quality with a stainless steel shaft and solder lug terminals. With durability in mind the 534 series are rated for over one million lifecycles and are suitable for industrial control applications, medical instruments, wire cutting machines and welding machines.
The 534 series are all rotary potentiometers. This means the shaft is housed by a knob. Turning the shaft will operate the wiper and adjust the resistance.
The 534 series are all rotary potentiometers. This means the shaft is housed by a knob. Turning the shaft will operate the wiper and adjust the resistance.
Features and Benefits –
• Wire-wound design
• Built with quality in mind so you can use these potentiometers in a rugged environment.
• Sealed body provides additional protection
• Rated at 1 Million lifecycles
• Solder lug termination
• Supplied with a metal lock and washer
• Ten turns with a 5% tolerance
• Sleeve bearing type.
• ±0.25% Linearity
• Built with quality in mind so you can use these potentiometers in a rugged environment.
• Sealed body provides additional protection
• Rated at 1 Million lifecycles
• Solder lug termination
• Supplied with a metal lock and washer
• Ten turns with a 5% tolerance
• Sleeve bearing type.
• ±0.25% Linearity
Precision - Multi-Turn and Servo
Specifications
Attribute | Value |
|---|---|
| Potentiometer Type | Rotary |
| Maximum Resistance | 100Ω |
| Number of Gangs | 1 |
| Number of Turns | 10 |
| Power Rating | 2W |
| Electrical Taper | Linear |
| Element Material | Wirewound |
| Mounting Type | Panel Mount |
| Termination Style | Solder Lug |
| Shaft Length | 20.6mm |
| Shaft Diameter | 6.35 mm |
| Actuator Type | Slotted Shaft |
| Tolerance | ±5% |
| Series | 534 |
