Vishay P16F 10 mΩ Rotary Potentiometer 1-Turns 1-Gang Panel Mount, P16FNP102KACV1D

View all Potentiometers

Subtotal (1 box of 20 units)*

£250.24

(exc. VAT)

£300.28

(inc. VAT)

Add to Basket
Select or type quantity
Stock information currently inaccessible - Please check back later
Units
Per unit
Per Box*
20 +£12.512£250.24

*price indicative

RS Stock No.:
298-404
Mfr. Part No.:
P16FNP102KACV1D
Brand:
Vishay
Find similar products by selecting one or more attributes.
Select all

Brand

Vishay

Potentiometer Type

Rotary

Product Type

Potentiometer

Maximum Resistance

10mΩ

Shaft Diameter

10mm

Number of Gangs

1

Number of Turns

1

Packaging

Carton Box of 20 pieces

Power Rating

1W

Electrical Taper

Linear

Element Material

Cermet

Mount Type

Panel Mount

Termination Style

Solder Lug

Shaft Length

18mm

Minimum Operating Temperature

-40°C

Pin Count

3

Maximum Operating Temperature

85°C

Standards/Approvals

IEC 60393-1, RoHS

Length

33.5mm

Actuator Type

Knob

Tolerance ±

10%

Series

P16F

COO (Country of Origin):
CZ
The Vishay Potentiometer features a cermet design with minimal clearance requirements. It is available in versions for professional and industrial applications as well as professional audio applications. The potentiometer offers high dielectric strength and is tested according to CECC 41000 or IEC 60393-1.

Fully sealed and panel sealed

Metallic knob special marking or custom knob on request

Custom knob and marking on request

Detent option on request haptic technology
