Wurth Elektronik 100 μF Through Hole Polymer Capacitor, 16 V dc
- RS Stock No.:
- 839-2136
- Mfr. Part No.:
- 870025374001
- Brand:
- Wurth Elektronik
Bulk discount available
Subtotal (1 pack of 5 units)*
£2.67
(exc. VAT)
£3.205
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- Plus 75 unit(s) shipping from 30 March 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Pack* |
|---|---|---|
| 5 - 20 | £0.534 | £2.67 |
| 25 - 45 | £0.45 | £2.25 |
| 50 - 95 | £0.402 | £2.01 |
| 100 - 495 | £0.342 | £1.71 |
| 500 + | £0.294 | £1.47 |
*price indicative
- RS Stock No.:
- 839-2136
- Mfr. Part No.:
- 870025374001
- Brand:
- Wurth Elektronik
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Wurth Elektronik | |
| Product Type | Polymer Capacitor | |
| Technology | Polymer | |
| Capacitance | 100μF | |
| Voltage | 16 V dc | |
| Mount Type | Through Hole | |
| Package/Case | 800 | |
| Lead Pitch | 3.5mm | |
| Tolerance | ±20 % | |
| Maximum Operating Temperature | 105°C | |
| Dimensions | 8 (Dia) x 11.5 mm | |
| Length | 11.5mm | |
| Series | WCAP-PTG5 | |
| Height | 11.5mm | |
| Minimum Operating Temperature | -55°C | |
| Ripple Current | 4.8A | |
| Dissipation Factor | 8% | |
| Lifetime | 2000 h | |
| Leakage Current | 160μA | |
| Diameter | 8 mm | |
| Automotive Standard | No | |
| Select all | ||
|---|---|---|
Brand Wurth Elektronik | ||
Product Type Polymer Capacitor | ||
Technology Polymer | ||
Capacitance 100μF | ||
Voltage 16 V dc | ||
Mount Type Through Hole | ||
Package/Case 800 | ||
Lead Pitch 3.5mm | ||
Tolerance ±20 % | ||
Maximum Operating Temperature 105°C | ||
Dimensions 8 (Dia) x 11.5 mm | ||
Length 11.5mm | ||
Series WCAP-PTG5 | ||
Height 11.5mm | ||
Minimum Operating Temperature -55°C | ||
Ripple Current 4.8A | ||
Dissipation Factor 8% | ||
Lifetime 2000 h | ||
Leakage Current 160μA | ||
Diameter 8 mm | ||
Automotive Standard No | ||
Wurth Elektronik General Purpose WCAP-PTG5 Capacitor Series 105°C
Aluminium Polymer capacitors contain solid conductive polymer instead of wet electrolytic thus the benefits are:
High permissible ripple current due to lower ESR at high frequency range
Higher long term stability and expected life
No dry out phenomenon due to solid conductive polymer
Features and Benefits
• Low ESR at high frequency range
• High permissible ripple current
• Load life of 2000 h @ +105°C
• Operating temperature: -55°C to +105°C
• Wave soldering is recommended
Solid Radial 105°C
