KEMET 270μF Surface Mount Polymer Capacitor, 40V dc

View all Polymer Capacitors
Currently unavailable
We don’t know if this item will be back in stock, it is being discontinued by the manufacturer.
RS Stock No.:
209-5425
Mfr. Part No.:
A768MS277M1GLAV022
Brand:
KEMET
Find similar products by selecting one or more attributes.
Select all

Brand

KEMET

Technology

Polymer

Capacitance

270µF

Voltage

40 V dc, 46V dc

Dielectric Material Family

Aluminium

Mounting Type

Surface Mount

Equivalent Series Resistance

22mΩ

Lead Pitch

3.2mm

Tolerance

±20%

Length

12.4mm

Maximum Operating Temperature

+125°C

Dimensions

10 (Dia) x 12.4mm

Series

A768

Minimum Operating Temperature

-55°C

Lifetime

2000h

Diameter

10mm

Automotive Standard

AEC-Q200

Ripple Current

2200mA

COO (Country of Origin):
CN
The KEMET surface mount aluminium polymer capacitor operates on 40V DC and have capacitance range of 270uF with capacitance tolerance of ±20% .It has maximum operating temperature of 125 °C and ripple current 2,200mA. Its dimensions are 10x12.2mm in size.

Capacitance 270uF
Voltage Rating 40V
Ripple Current 2,200mA
Dimensions 10x12.2mm
Tolerance 20%
