KEMET 68μF Through Hole Polymer Capacitor, 63V dc
- RS Stock No.:
- 173-9295
- Mfr. Part No.:
- A759MS686M1JAAE047
- Brand:
- KEMET
Unavailable
RS will no longer stock this product.
- RS Stock No.:
- 173-9295
- Mfr. Part No.:
- A759MS686M1JAAE047
- Brand:
- KEMET
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | KEMET | |
| Technology | Electrolytic | |
| Capacitance | 68µF | |
| Dielectric Material Family | Aluminium | |
| Voltage | 63V dc | |
| Mounting Type | Through Hole | |
| Equivalent Series Resistance | 47mΩ | |
| Lead Pitch | 5mm | |
| Tolerance | ±20% | |
| Length | 31mm | |
| Maximum Operating Temperature | +125°C | |
| Height | 12mm | |
| Dimensions | 10 (Dia) x 12mm | |
| Series | A759 | |
| Electrolyte Type | Solid | |
| Dissipation Factor | 12% | |
| Leakage Current | 642.6 μA | |
| Lifetime | 2000h | |
| Polarised | Polar | |
| Ripple Current | 1.97A | |
| Minimum Operating Temperature | -55°C | |
| Diameter | 10mm | |
| Select all | ||
|---|---|---|
Brand KEMET | ||
Technology Electrolytic | ||
Capacitance 68µF | ||
Dielectric Material Family Aluminium | ||
Voltage 63V dc | ||
Mounting Type Through Hole | ||
Equivalent Series Resistance 47mΩ | ||
Lead Pitch 5mm | ||
Tolerance ±20% | ||
Length 31mm | ||
Maximum Operating Temperature +125°C | ||
Height 12mm | ||
Dimensions 10 (Dia) x 12mm | ||
Series A759 | ||
Electrolyte Type Solid | ||
Dissipation Factor 12% | ||
Leakage Current 642.6 μA | ||
Lifetime 2000h | ||
Polarised Polar | ||
Ripple Current 1.97A | ||
Minimum Operating Temperature -55°C | ||
Diameter 10mm | ||
- COO (Country of Origin):
- CN
KEMET’s A759 Single-Ended Conductive Polymer AluminumSolid Electrolytic Capacitors offer longer life and greater stability across a wide range of temperatures. The A759 highly conductive solid polymer electrolyte eliminates the risk of explosion from drying out and due to its low ESR properties, is able to withstand higher ripple currents duringnormal operation. The A759 is ideally suited for industrial and commercial applications. Typical applications include long life LED drivers, professional power amplifiers and industrial power supplies).
Through-hole form factor
High Voltage
Low impedance
High ripple current
125°C/2,000 hours
High Voltage
Low impedance
High ripple current
125°C/2,000 hours
